Trumeter 3G-OTH-28819 — Technical Specifications
The TRUMETER APM-FREQ-ANO is a Frequency Digital Panel Meter from the APM series, featuring a red LCD digital display with a 9-span range (min 9,999, max 9,999). It offers 0.5% accuracy, True RMS AC magnitude calculation, and an RS-485 interface, with internal removable terminal blocks for connection. The meter is housed in a NEMA 4-rated enclosure and operates on 12 V AC to 24 V AC power.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | TRUMETER |
| Series | APM |
| Accuracy | 0.5% |
| Interface | RS-485 |
| Input Type | Frequency |
| Product Type | Frequency Meter |
| Display Features | Graph |
| NEMA Enclosure Rating | 4 |
| AC Magnitude Calculation | True RMS |
| Manufacturer Part Number | APM-FREQ-ANO |
| Terminal Connection Type | Internal Removable Terminal Blocks |
| Digital Display Screen Type | LCD |
| Digital Display Screen Color | Red |
