WIDIA POSITIVE INSERT

WIDIA, a brand with a history rooted in the development of cemented carbide cutting tools, is recognized globally for its indexable turning inserts. The WIDIA POSITIVE INSERT line encompasses a range of geometries and chipbreaker designs engineered for turning operations on a variety of workpiece materials. These inserts are characterized by positive rake angles, which reduce cutting forces and heat generation, making them suitable for applications involving thin-walled components, long-chipping materials, and machines with limited rigidity. The product family includes diamond-shaped (CCMT, CCGT) and square-shaped (SCMT) inserts, each available in multiple sizes and edge preparations. Key geometries offered include the GEO 1P, designed for general-purpose turning with a sharp edge and low cutting forces; the GEO MU, a multi-purpose geometry optimized for medium to finishing cuts on steels and stainless steels; and the GEO AL, specifically formulated for aluminum and non-ferrous alloys, featuring a polished rake face to minimize built-up edge. Inserts are manufactured to standard tolerances (typically class M or U) and are compatible with a wide range of tool holders. 3G Electric stocks 38 SKUs of WIDIA POSITIVE INSERT indexable turning inserts, providing datasheets and logistics support for global procurement. The selection covers common insert sizes such as CCMT3252 (09T308), CCMT2151 (060204), and SCMT432 (120408), ensuring availability for typical lathe tooling setups. Each insert is supplied with manufacturer part numbers for traceability and cross-referencing. The inserts are uncoated or coated depending on the geometry, with the GEO AL featuring a polished surface for non-ferrous work. The positive geometry contributes to lower power consumption and improved surface finish compared to negative rake inserts, particularly in smaller lathes or when machining softer materials. For engineers and buyers, the WIDIA POSITIVE INSERT line offers a standardized solution for turning operations where chip control and edge security are required across a range of feeds and depths of cut. 3G Electric supports this line with technical datasheets and global shipping, enabling maintenance and production teams to maintain consistent tooling performance.

Genuine
OEM Parts
Expert
Tech Support
1 Day
Quote Response
Worldwide
Origin
Worldwide Shipping
Air & sea freight
Datasheets on Request
Technical specs & drawings
1-Day Quote Response
Singapore-based team
Show
Page 1 of 1

About WIDIA POSITIVE INSERT

WIDIA, a brand with a history rooted in the development of cemented carbide cutting tools, is recognized globally for its indexable turning inserts. The WIDIA POSITIVE INSERT line encompasses a range of geometries and chipbreaker designs engineered for turning operations on a variety of workpiece materials. These inserts are characterized by positive rake angles, which reduce cutting forces and heat generation, making them suitable for applications involving thin-walled components, long-chipping materials, and machines with limited rigidity. The product family includes diamond-shaped (CCMT, CCGT) and square-shaped (SCMT) inserts, each available in multiple sizes and edge preparations. Key geometries offered include the GEO 1P, designed for general-purpose turning with a sharp edge and low cutting forces; the GEO MU, a multi-purpose geometry optimized for medium to finishing cuts on steels and stainless steels; and the GEO AL, specifically formulated for aluminum and non-ferrous alloys, featuring a polished rake face to minimize built-up edge. Inserts are manufactured to standard tolerances (typically class M or U) and are compatible with a wide range of tool holders. 3G Electric stocks 38 SKUs of WIDIA POSITIVE INSERT indexable turning inserts, providing datasheets and logistics support for global procurement. The selection covers common insert sizes such as CCMT3252 (09T308), CCMT2151 (060204), and SCMT432 (120408), ensuring availability for typical lathe tooling setups. Each insert is supplied with manufacturer part numbers for traceability and cross-referencing. The inserts are uncoated or coated depending on the geometry, with the GEO AL featuring a polished surface for non-ferrous work. The positive geometry contributes to lower power consumption and improved surface finish compared to negative rake inserts, particularly in smaller lathes or when machining softer materials. For engineers and buyers, the WIDIA POSITIVE INSERT line offers a standardized solution for turning operations where chip control and edge security are required across a range of feeds and depths of cut. 3G Electric supports this line with technical datasheets and global shipping, enabling maintenance and production teams to maintain consistent tooling performance.

Common Applications

  • General turning of carbon steel shafts — WIDIA POSITIVE INSERT GEO MU (CCMT3252MU)
  • Finishing cuts on stainless steel flanges — WIDIA POSITIVE INSERT GEO 1P (CCMT09T3081P)
  • Aluminum component machining in automotive — WIDIA POSITIVE INSERT GEO AL (CCGT060208AL)
  • Square shoulder turning on alloy steel blocks — WIDIA POSITIVE INSERT GEO MU (SCMT120408MU)
  • Light roughing of thin-walled tubes — WIDIA POSITIVE INSERT GEO 1P (CCMT21511P)
  • Non-ferrous bushing production — WIDIA POSITIVE INSERT GEO AL (CCGT2152AL)

Frequently asked questions

Common questions about WIDIA POSITIVE INSERT from 3G Electric.

What is the difference between WIDIA POSITIVE INSERT geometries GEO 1P, GEO MU, and GEO AL?

The GEO 1P is a general-purpose geometry with a sharp cutting edge, designed for low cutting forces and good surface finish on steels and cast irons. GEO MU is a multi-purpose geometry optimized for medium to finishing cuts on steels and stainless steels, offering a balance of edge strength and chip control. GEO AL is specifically engineered for aluminum and non-ferrous alloys, featuring a polished rake face to reduce built-up edge and improve chip evacuation. Each geometry is available in specific insert shapes and sizes, such as CCMT or SCMT, to match application requirements.

Are WIDIA POSITIVE INSERT indexable turning inserts coated or uncoated?

The WIDIA POSITIVE INSERT line includes both uncoated and coated variants depending on the geometry. For example, the GEO AL geometry typically features an uncoated, polished surface for non-ferrous machining, while GEO MU inserts may be coated with materials like TiN or TiCN for enhanced wear resistance on steels. The specific coating or lack thereof is indicated by the insert grade designation. Refer to the manufacturer part number and datasheet for coating details.

What materials can be machined with WIDIA POSITIVE INSERT GEO MU inserts?

WIDIA POSITIVE INSERT GEO MU inserts are designed for turning operations on a range of materials including carbon steels, alloy steels, and stainless steels. The multi-purpose geometry provides effective chip control at medium to light depths of cut and moderate feed rates. These inserts are suitable for both roughing and finishing passes, depending on the specific grade and coating. For optimal performance, select the appropriate grade based on workpiece hardness and cutting conditions.

How do I identify the correct WIDIA POSITIVE INSERT for my tool holder?

WIDIA POSITIVE INSERT inserts follow the ISO standard for indexable inserts, with designations such as CCMT3252 or SCMT120408. The first letter indicates shape (C for diamond 80°, S for square), the second letter indicates clearance angle (C for 7°), and the third letter indicates tolerance class (M or U). The numbers indicate insert size (e.g., 3252 corresponds to 3/8 inch inscribed circle and 5/32 inch thickness). Match these dimensions to your tool holder's pocket size and clamping mechanism. 3G Electric provides datasheets with full specifications for cross-referencing.

Can WIDIA POSITIVE INSERT inserts be used for both roughing and finishing operations?

Yes, but the appropriate geometry must be selected. GEO 1P is suited for finishing due to its sharp edge and low cutting forces, while GEO MU can handle medium roughing and finishing on steels. For heavy roughing, negative rake inserts are typically recommended. The positive rake design of these inserts inherently limits depth of cut and feed rate compared to negative rake inserts, so they are best applied in light to moderate material removal scenarios. Always consult the manufacturer's recommended cutting data for each geometry.

Does 3G Electric supply WIDIA POSITIVE INSERT products?

Yes — 3G Electric (S) Pte. Ltd. supplies WIDIA POSITIVE INSERT products. We stock the WIDIA POSITIVE INSERT catalog and supply genuine factory-original products with full manufacturer warranty and technical support.
