COLOR-KEYED KUBE

Color-Keyed Kube is a product line of Thomas & Betts, a brand under ABB Installation Products, specializing in color-coded compression connectors and tooling for electrical power connections. The Color-Keyed Kube system is designed for use with hydraulic crimping tools to create reliable, code-compliant connections on copper and aluminum conductors. The product family includes remote-powered crimping heads and a wide range of upper and lower replacement crimping dies, each color-coded to match specific connector sizes and conductor materials. Dies are available for conductor sizes from 4/0 AWG to 1000 kcmil, covering copper lugs, aluminum lugs, and copper/aluminum connectors. The color-coding system simplifies die selection and reduces installation errors, as each die set is marked with a distinct color (e.g., orange, black, red, purple, pink, blue) corresponding to a specific connector range. The remote-powered crimping head (MPN 13100A) is rated for 900 kcmil max copper and 750 kcmil max aluminum, and is designed for use with compatible hydraulic pumps. Dies are constructed from hardened steel for durability and consistent crimp profiles. 3G Electric stocks a selection of Color-Keyed Kube replacement dies and crimping heads, supporting maintenance and repair of existing tooling. The line is applicable in electrical construction, utility, industrial, and commercial installations where compression connections are required. All components are designed to meet applicable industry standards for electrical connections, including UL and CSA requirements where specified. The color-keyed system is a practical solution for reducing inventory complexity and ensuring correct die-to-connector matching in field and shop environments.

Genuine
OEM Parts
Expert
Tech Support
1 Day
Quote Response
Worldwide
Origin
Worldwide Shipping
Air & sea freight
Datasheets on Request
Technical specs & drawings
1-Day Quote Response
Singapore-based team
Show
Page 1 of 1

About COLOR-KEYED KUBE

Color-Keyed Kube is a product line of Thomas & Betts, a brand under ABB Installation Products, specializing in color-coded compression connectors and tooling for electrical power connections. The Color-Keyed Kube system is designed for use with hydraulic crimping tools to create reliable, code-compliant connections on copper and aluminum conductors. The product family includes remote-powered crimping heads and a wide range of upper and lower replacement crimping dies, each color-coded to match specific connector sizes and conductor materials. Dies are available for conductor sizes from 4/0 AWG to 1000 kcmil, covering copper lugs, aluminum lugs, and copper/aluminum connectors. The color-coding system simplifies die selection and reduces installation errors, as each die set is marked with a distinct color (e.g., orange, black, red, purple, pink, blue) corresponding to a specific connector range. The remote-powered crimping head (MPN 13100A) is rated for 900 kcmil max copper and 750 kcmil max aluminum, and is designed for use with compatible hydraulic pumps. Dies are constructed from hardened steel for durability and consistent crimp profiles. 3G Electric stocks a selection of Color-Keyed Kube replacement dies and crimping heads, supporting maintenance and repair of existing tooling. The line is applicable in electrical construction, utility, industrial, and commercial installations where compression connections are required. All components are designed to meet applicable industry standards for electrical connections, including UL and CSA requirements where specified. The color-keyed system is a practical solution for reducing inventory complexity and ensuring correct die-to-connector matching in field and shop environments.

Common Applications

  • Electrical utility substation — Color-Keyed Kube remote-powered crimping head (MPN 13100A) for large copper/aluminum cable terminations
  • Industrial plant maintenance — Color-Keyed Kube replacement dies (SKU 3LK29) for 800 kcmil copper lug crimping in motor control centers
  • Commercial building construction — Color-Keyed Kube dies (SKU 3LK08) for 300 kcmil copper/4/0 AWG aluminum connections in switchgear
  • Renewable energy installations — Color-Keyed Kube dies (SKU 3LK18) for 650 kcmil aluminum cable terminations in solar farm inverters
  • Data center power distribution — Color-Keyed Kube dies (SKU 3LK30) for 700 kcmil aluminum/copper connections in UPS systems
  • Mining and heavy industry — Color-Keyed Kube dies (SKU 3LK33) for 4/0 AWG to 1000 kcmil aluminum lug crimping in portable power cables

Frequently asked questions

Common questions about COLOR-KEYED KUBE from 3G Electric.

What conductor sizes do Color-Keyed Kube replacement crimping dies cover?

Color-Keyed Kube replacement crimping dies are available for conductor sizes ranging from 4/0 AWG to 1000 kcmil. Specific die sets cover copper lugs, aluminum lugs, and copper/aluminum connectors. For example, SKU 3LK32 covers 4/0 AWG to 500 kcmil aluminum lugs, while SKU 3LK33 covers 4/0 AWG to 1000 kcmil aluminum lugs. Dies for copper conductors include sizes up to 800 kcmil (SKU 3LK29) and 750 kcmil (SKU 3LK18). Always verify the die's rated conductor range and material compatibility before use.

How does the color-coding system work for Color-Keyed Kube dies?

Each Color-Keyed Kube die set is assigned a specific color (e.g., orange, black, red, purple, pink, blue) that corresponds to a particular connector size and material combination. The color is marked on the die body and matches the color band on compatible Color-Keyed connectors. This system allows technicians to quickly select the correct die for a given connector without referencing a chart, reducing the risk of mismatched crimps. For example, a purple die (SKU 3LK30) is used with 700 kcmil aluminum/copper connectors, while a blue die (SKU 3LK08) is for 300 kcmil copper/4/0 AWG aluminum lugs.

What hydraulic crimping tools are compatible with Color-Keyed Kube remote-powered crimping heads?

The Color-Keyed Kube remote-powered crimping head (MPN 13100A) is designed for use with compatible hydraulic pumps that provide the necessary flow and pressure. It is a remote head, meaning it is connected to a separate power unit via hydraulic hoses. The head accepts standard Color-Keyed Kube dies and is rated for 900 kcmil max copper and 750 kcmil max aluminum. For specific pump compatibility, refer to the manufacturer's documentation. 3G Electric supplies the crimping head and replacement dies but does not list pump models in the current inventory.

Are Color-Keyed Kube dies suitable for both copper and aluminum connectors?

Yes, many Color-Keyed Kube dies are designed for use with both copper and aluminum connectors. For instance, SKU 3LK29 is specified for 800 kcmil copper and copper/aluminum connectors, while SKU 3LK18 covers 650 kcmil aluminum and 750 kcmil copper. However, some dies are material-specific, such as SKU 3LK32 and SKU 3LK33, which are for aluminum lugs only. Always check the die's specifications to confirm compatibility with the connector material and type.

What is the difference between a Color-Keyed Kube crimping head and replacement dies?

The Color-Keyed Kube crimping head (e.g., MPN 13100A) is the tool body that houses the dies and applies the crimping force. It is a remote-powered unit that connects to a hydraulic pump. Replacement dies are the interchangeable upper and lower die sets that fit into the crimping head. Each die set is designed for a specific conductor size and material. The head remains the same, while dies are swapped based on the connector being installed. 3G Electric stocks both the crimping head and individual die sets for maintenance and replacement.

Does 3G Electric supply COLOR-KEYED KUBE products?

Yes — 3G Electric (S) Pte. Ltd. supplies COLOR-KEYED KUBE products. We stock the COLOR-KEYED KUBE catalog and supply genuine factory-original products with full manufacturer warranty and technical support.
