FSQ

FSQ is a manufacturer of bearing accessories, primarily known for its range of withdrawal sleeves and bearing lock washers. The brand supplies components designed for mounting and securing bearings on shafts, with products that conform to standard metric and inch dimensions. FSQ withdrawal sleeves, such as the AHX series, are constructed from chrome steel and feature metric threads with sizes ranging from M80x2 to M145x2, accommodating bore diameters from 65 mm to 125 mm and overall widths from 64 mm to 115 mm. These sleeves are available with tapers of 1:12, suitable for adapting bearings to shafts. FSQ bearing lock washers, like the W44 and W28 models, are made from steel and are designed to fit specific lock nuts and bearing series, with face diameters up to 9.875 inches for nominal shaft diameters up to 8 11/16 inches. The product line supports industrial applications where precise shaft mounting and bearing retention are required, such as in pumps, compressors, conveyors, and gearboxes. 3G Electric stocks a range of FSQ withdrawal sleeves and bearing lock washers, offering multiple SKUs to cover common bore sizes and thread configurations. The inventory includes both metric and inch variants, enabling procurement specialists to source components for diverse equipment without extended lead times. 3G Electric provides logistics support for global shipments, ensuring that FSQ components are available to plant engineers and maintenance managers worldwide. The focus is on supplying standardized, functional parts that meet dimensional specifications, without embellishment or unverified claims about performance.

Genuine
OEM Parts
Expert
Tech Support
1 Day
Quote Response
Worldwide
Origin
Worldwide Shipping
Air & sea freight
Datasheets on Request
Technical specs & drawings
1-Day Quote Response
Singapore-based team
Show
Page 1 of 3
← Prev123Next →

About FSQ

FSQ is a manufacturer of bearing accessories, primarily known for its range of withdrawal sleeves and bearing lock washers. The brand supplies components designed for mounting and securing bearings on shafts, with products that conform to standard metric and inch dimensions. FSQ withdrawal sleeves, such as the AHX series, are constructed from chrome steel and feature metric threads with sizes ranging from M80x2 to M145x2, accommodating bore diameters from 65 mm to 125 mm and overall widths from 64 mm to 115 mm. These sleeves are available with tapers of 1:12, suitable for adapting bearings to shafts. FSQ bearing lock washers, like the W44 and W28 models, are made from steel and are designed to fit specific lock nuts and bearing series, with face diameters up to 9.875 inches for nominal shaft diameters up to 8 11/16 inches. The product line supports industrial applications where precise shaft mounting and bearing retention are required, such as in pumps, compressors, conveyors, and gearboxes. 3G Electric stocks a range of FSQ withdrawal sleeves and bearing lock washers, offering multiple SKUs to cover common bore sizes and thread configurations. The inventory includes both metric and inch variants, enabling procurement specialists to source components for diverse equipment without extended lead times. 3G Electric provides logistics support for global shipments, ensuring that FSQ components are available to plant engineers and maintenance managers worldwide. The focus is on supplying standardized, functional parts that meet dimensional specifications, without embellishment or unverified claims about performance.

Common Applications

  • Pump assembly — FSQ AHX3220 withdrawal sleeve used to mount bearings on pump shafts in water treatment facilities.
  • Conveyor systems — FSQ AHX2315 withdrawal sleeve for securing bearings on conveyor roller shafts in material handling.
  • Compressor maintenance — FSQ W44 bearing lock washer used with lock nuts to retain bearings on compressor shafts.
  • Gearbox repair — FSQ AHX2326 withdrawal sleeve for mounting bearings on gearbox input shafts in industrial drives.
  • Fan and blower applications — FSQ W28 bearing lock washer for securing bearings on fan shafts in HVAC systems.
  • Machine tool spindles — FSQ AHX3122 withdrawal sleeve for precise bearing mounting on spindle assemblies.

Frequently asked questions

Common questions about FSQ from 3G Electric.

What materials are used in FSQ withdrawal sleeves?

FSQ withdrawal sleeves, such as the AHX3220 and AHX2314, are manufactured from chrome steel. This material provides hardness and wear resistance suitable for repeated mounting and dismounting of bearings on shafts. Chrome steel is a standard choice for bearing accessories due to its dimensional stability under load.

What thread sizes are available for FSQ withdrawal sleeves?

FSQ withdrawal sleeves feature metric threads. Common thread sizes include M80x2, M85x2, M110x2, M120x2, M125x2, and M145x2, depending on the sleeve model. These threads are designed to match corresponding lock nuts and facilitate secure axial positioning on shafts.

Are FSQ bearing lock washers compatible with specific lock nuts?

Yes, FSQ bearing lock washers are designed for use with specific lock nuts. For example, the W44 lock washer is compatible with lock nut W44, and the W28 lock washer is compatible with lock nut AN28. This ensures proper engagement and locking of the bearing assembly on the shaft.

What taper ratios are available on FSQ withdrawal sleeves?

FSQ withdrawal sleeves are available with a 1:12 taper, as seen in models like AHX2326 and AHX3122. This taper is standard for adapting bearings with a 1:12 bore taper to cylindrical shafts, allowing for precise interference fit and easy removal.

Can FSQ withdrawal sleeves be used with metric bearings?

Yes, FSQ withdrawal sleeves are designed for metric bearings. The bore diameters range from 65 mm to 125 mm, and the sleeves are intended for use with bearings that have a corresponding bore size and taper. The metric thread sizes also align with standard metric lock nuts.

Does 3G Electric supply FSQ products?

Yes — 3G Electric (S) Pte. Ltd. supplies FSQ products. We stock the FSQ catalog and supply genuine factory-original products with full manufacturer warranty and technical support.
