Pcs 3G-OTH-227436 — Technical Specifications

Name: Pcs 3G-OTH-227436 PCS Step Ejector Pin: Step Pin, Tool Steel, 1/32 in Nom. Dia., 8 in Overall Lg, 1/8 in Shoulder Dia (MPN SP3-83). Key specifications — attr1132749: +0.062/-0.000 in; attr1110848: PCS; attr1132750: +0.0000/-0.0003 in; attr1132753: 0.03 in.
Brand: Pcs

The PCS Step Ejector Pin: Step Pin is a general purpose stepped ejector pin made of tool steel. It has a nominal diameter of 1/32 in, an overall length of 8 in, and a shoulder diameter of 1/8 in. Key tolerances include +0.062/-0.000 in for one dimension and +0.0000/-0.0003 in for another, with a step height of 0.03 in.

View Product & Quote

Technical Specifications

Parameter	Value
Attr1110848	PCS
Attr1132749	+0.062/-0.000 in
Attr1132750	+0.0000/-0.0003 in
Attr1132753	0.03 in
Manufacturer Part Number	SP3-83
