Crydom 3G-OTH-36804 — Technical Specifications

Name: Crydom 3G-OTH-36804 CRYDOM Solid State Relay: DIN-Rail Mounted, 45 A Max Output Current, SCR, AC Output (MPN CMRA4845). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Cage Type; Finger Safe: Yes; Input Current: 15 mA; Maximum Output Current without Heat Sink: 45 A; Mounting Style: DIN Rail; Output Voltage: 48 to 530V AC.
Brand: Crydom

The CRYDOM CMRA4845 is a DIN-Rail Mounted Solid State Relay with an AC output, featuring a Form A (SCR) switch configuration. It supports an output voltage range of 48 to 530V AC and a maximum output current of 45 A without a heat sink, with an input current of 15 mA. The relay offers a cage-type electrical connection and is finger safe for enhanced safety during installation.

View Product & Quote

Technical Specifications

Parameter	Value
Brand	CRYDOM
Finger Safe	Yes
Current Type	AC
Input Current	15 mA
Mounting Style	DIN Rail
Output Voltage	48 to 530V AC
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Cage Type
Manufacturer Part Number	CMRA4845
Maximum Output Current Without Heat Sink	45 A
