Crydom 3G-OTH-36704 — Technical Specifications

Name: Crydom 3G-OTH-36704 CRYDOM Solid State Relay: DIN-Rail Mounted, 30 A Max Output Current, SCR, AC Output (MPN CKRD2430). Key specifications — Brand: CRYDOM; Current Type: DC; Electrical Connection: Box Clamp; Finger Safe: Yes; Input Current: 8 to 12 mA; Maximum Output Current without Heat Sink: 30 A; Mounting Style: DIN Rail; Output Voltage: 24 to 280V AC.
Brand: Crydom

The CRYDOM CKRD2430 is a DIN-Rail Mounted Solid State Relay with a DC input current of 8 to 12 mA and an AC output voltage of 24 to 280V AC. It features a Form A switch configuration, a maximum output current of 30 A without a heat sink, and a box clamp electrical connection. This SCR-based relay is finger safe and designed for DIN-rail mounting.

View Product & Quote

Technical Specifications

Parameter	Value
Brand	CRYDOM
Finger Safe	Yes
Current Type	DC
Input Current	8 to 12 mA
Mounting Style	DIN Rail
Output Voltage	24 to 280V AC
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Box Clamp
Manufacturer Part Number	CKRD2430
Maximum Output Current Without Heat Sink	30 A
