Crydom 3G-OTH-39174 — Technical Specifications
The CRYDOM D06D80 is a panel-mounted solid-state relay with a DC output, featuring a Form A switch configuration and screw-clamp electrical connections. It operates with a 15 mA input current and an output voltage range of 1 to 48V DC, with a maximum output current of 80 A. This relay is not finger-safe and is not recommended for use without a heat sink.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | CRYDOM |
| Finger Safe | No |
| Current Type | DC |
| Input Current | 15 mA |
| Mounting Style | Panel |
| Output Voltage | 1 to 48V DC |
| Switch Configuration | Form A |
| Voltage/Current Type | DC Output |
| Electrical Connection | Screw Clamp |
| Manufacturer Part Number | D06D80 |
| Maximum Output Current Without Heat Sink | Not Recommended |
