Crydom 3G-OTH-40212 — Technical Specifications
The CRYDOM HA4850E is a panel-mounted solid-state relay with an AC output, featuring a Form A (SPST-NO) switch configuration. It accepts an input voltage of 18-36 VAC with a 10 mA input current, and its output voltage range is 48 to 530V AC. The relay uses a screw-clamp electrical connection and has a maximum output current of 12 A without a heat sink.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | CRYDOM |
| Finger Safe | No |
| Current Type | AC |
| Input Current | 10 mA |
| Input Voltage | 18-36 VAC |
| Mounting Style | Panel |
| Output Voltage | 48 to 530V AC |
| Switch Configuration | Form A |
| Voltage/Current Type | AC Output |
| Electrical Connection | Screw Clamp |
| Manufacturer Part Number | HA4850E |
| Maximum Output Current Without Heat Sink | 12 A |
