APPLETON ELECTRIC Conduit Outlet Body: Iron, GRF, 1 in Trade Size, X Body - X, XAT and XTF Round Body - Cross Type
APPLETON ELECTRICX, XAT and XTF Round Body - Cross Type

APPLETON ELECTRIC Conduit Outlet Body: Iron, GRF, 1 in Trade Size, X Body

The Appleton Electric GRFX100 is an iron conduit outlet body with a Triple Coat Epoxy Coating, part of the For Standard Body series. This X-style body has a 1 in trade size, 18 cu in capacity, threaded female hubs…

SKU 3G-OTH-06486

Brand
APPLETON ELECTRIC
Item
Conduit Outlet Body: Iron, GRF, 1 in Trade Size, X Body
Category
X, XAT and XTF Round Body - Cross Type
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPLETON ELECTRIC
Manufacturer Part Number
GRFX100
Series
For Standard Body
Material
Iron
Finish
Triple Coat Epoxy Coating
Back Type
Flat
Body Type
Conduit Outlet Body
Hub Style
Threaded
Standards
CSA C22.2 No. 25
Body Style
X
For Use With
Threaded IMC
Thread Gender
Female
Cover Included
Yes
Connection Type
Threaded
Special Features
Flanged
Hazardous Location
Yes
Compatible Conduit Trade Size
1 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPLETON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Appleton Electric GRFX100 is an iron conduit outlet body with a Triple Coat Epoxy Coating, part of the For Standard Body series. This X-style body has a 1 in trade size, 18 cu in capacity, threaded female hubs, and a flat back, designed for use with threaded IMC. It includes a cover, is flanged, and meets CSA C22.2 No. 25 standards for hazardous locations.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the Appleton Electric GRFX100 conduit outlet body used for?

The Appleton Electric GRFX100 is an iron X-style conduit outlet body used to provide a pull point or junction in threaded IMC runs. Its 18 cu in capacity and flat back suit industrial electrical installations, including hazardous locations per CSA C22.2 No. 25.

What are the specifications of the Appleton GRFX100 conduit outlet body?

The GRFX100 is an iron X-style body with a 1 in trade size, 18 cu in capacity, threaded female hubs, and a flat back. It includes a cover, has a Triple Coat Epoxy Coating, and is flanged. It meets CSA C22.2 No. 25 for hazardous locations.

Where to buy the Appleton GRFX100 conduit outlet body worldwide?

3G Electric supplies the Appleton GRFX100 conduit outlet body worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this X-style iron body.

How to install the Appleton GRFX100 conduit outlet body?

Install the GRFX100 by threading it onto threaded IMC conduit using the female hubs. Ensure the flat back mounts securely to a support surface. Tighten cover screws to maintain the hazardous-location seal. Follow NEC and CSA C22.2 No. 25 guidelines for proper bonding and grounding.
