APPLETON ELECTRIC Conduit Outlet Body: Iron, GR, 2 in Trade Size, X Body - X, XAT and XTF Round Body - Cross Type
APPLETON ELECTRICX, XAT and XTF Round Body - Cross Type

APPLETON ELECTRIC Conduit Outlet Body: Iron, GR, 2 in Trade Size, X Body

The Appleton Electric GRX200 is a 2-inch trade size, iron conduit outlet body with a round back and X body style. It features a triple-coat epoxy finish, threaded female hubs, and includes a cover and grounding…

SKU 3G-OTH-05313

Brand
APPLETON ELECTRIC
Item
Conduit Outlet Body: Iron, GR, 2 in Trade Size, X Body
Category
X, XAT and XTF Round Body - Cross Type
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPLETON ELECTRIC
Manufacturer Part Number
GRX200
Series
For Standard Body
Material
Iron
Finish
Triple Coat Epoxy Coating
Includes
Grounding Screw
Back Type
Round
Body Type
Conduit Outlet Body
Hub Style
Threaded
Standards
CSA C22.2 No. 25
Body Style
X
For Use With
Threaded IMC
Thread Gender
Female
Cover Included
Yes
Connection Type
Threaded
Hazardous Location
Yes
Compatible Conduit Trade Size
2 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPLETON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Appleton Electric GRX200 is a 2-inch trade size, iron conduit outlet body with a round back and X body style. It features a triple-coat epoxy finish, threaded female hubs, and includes a cover and grounding screw. Designed for use with threaded IMC, this CSA C22.2 No. 25 certified body is suitable for hazardous locations.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the Appleton Electric GRX200 conduit outlet body used for?

The Appleton Electric GRX200 is used to provide access to conductors in threaded IMC conduit systems, typically in hazardous locations. Its X body style and round back allow for pulling, splicing, or turning conductors in industrial environments where a CSA C22.2 No. 25 certified fitting is required.

What are the specifications of the Appleton Electric GRX200?

The GRX200 is a 2 in trade size, iron conduit outlet body with a triple-coat epoxy finish. It has threaded female hubs, a round back, X body style, and includes a cover and grounding screw. It is certified to CSA C22.2 No. 25 and is designed for use with threaded IMC in hazardous locations.

Where to buy the Appleton Electric GRX200 in worldwide?

3G Electric supplies the Appleton Electric GRX200 conduit outlet body to customers worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this CSA-certified fitting.

How to install the Appleton Electric GRX200 conduit outlet body?

Install the GRX200 by threading it onto threaded IMC conduit using the female hubs. Ensure the cover and gasket are properly seated, and tighten the cover screws. Connect the grounding screw to the system ground. Always follow local electrical codes and the manufacturer's instructions for hazardous location installations.

Used in

Common applications for APPLETON ELECTRIC
Oil and gas refineries — Appleton Electric EDSC21MC2 manual motor switch for controlling pumps in Class I, Division 1 areas
Chemical processing plants — Appleton Electric AEAB13420C hazardous location circuit breaker for motor protection in volatile environments
Pharmaceutical manufacturing — Appleton Electric FSK-1VDR weatherproof cover for duplex receptacles in washdown zones
Wastewater treatment facilities — Appleton Electric UNY250R-A aluminum conduit union for corrosion-resistant connections
Mining operations — Appleton Electric EDSC277-SA tandem 2-gang box for junction points in hazardous dust locations
Food and beverage processing — Appleton Electric JBK-75 iron cover for conduit access fittings in wet or dusty areas
