EATON Lighted Rocker Switch: 2 Positions, SPDT, On/On - General Purpose Rocker Switches
EATONGeneral Purpose Rocker Switches

EATON Lighted Rocker Switch: 2 Positions, SPDT, On/On

The EATON X-Series Lighted Rocker Switch (MPN XR3CG44NV1XX) is a general-purpose rocker switch with 2 positions, SPDT circuitry, and On/On operation. It features an amber illuminated operator and includes a lens…

SKU 3G-OTH-34968

Brand
EATON
Item
Lighted Rocker Switch: 2 Positions, SPDT, On/On
Category
General Purpose Rocker Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
XR3CG44NV1XX
Series
X
Horsepower
3/4 hp @ 277 V
Includes Lens
Lens Included
Displayed Brand
EATON
AC Contact Rating
16 A @ 125 V
Operator Illumination
Illuminated
Terminal Connection Type
0.25 in Quick Connect Tab
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON X-Series Lighted Rocker Switch (MPN XR3CG44NV1XX) is a general-purpose rocker switch with 2 positions, SPDT circuitry, and On/On operation. It features an amber illuminated operator and includes a lens, with an AC contact rating of 16 A @ 125 V and a horsepower rating of 3/4 hp @ 277 V. Termination is via 0.25 in quick connect tabs.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Used in

Common applications for EATON
Industrial control panels — Eaton M22 flush push buttons for momentary machine start/stop commands
Motor control centers — Eaton NEMA reversing starters with electronic overloads for conveyor belt direction control
HVAC systems — Eaton definite purpose starters with thermal overloads for compressor and fan motor protection
Process automation — Eaton SL7 tower lights with IP66 bases for visual status indication in wet environments
Machine tool signaling — Eaton 10250T LED pilot lights with push-to-test for operator panel status lamps
Access control — Eaton M22 keyed selector switches for equipment mode selection in secured areas

EATON Products

3G Electric supplies EATON general purpose rocker switches. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
