APPLETON ELECTRIC Conduit Outlet Body: Iron, GU, 1 in Trade Size, X Body - X, XAT and XTF Round Body - Cross Type
APPLETON ELECTRICX, XAT and XTF Round Body - Cross Type

APPLETON ELECTRIC Conduit Outlet Body: Iron, GU, 1 in Trade Size, X Body

The Appleton Electric GUX100 is a GU-series, X-style conduit outlet body made of iron with a triple-coat epoxy finish. It has a 1-inch trade size, a 19-cubic-inch body capacity, and threaded female hubs. This…

SKU 3G-OTH-05281

Brand
APPLETON ELECTRIC
Item
Conduit Outlet Body: Iron, GU, 1 in Trade Size, X Body
Category
X, XAT and XTF Round Body - Cross Type
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPLETON ELECTRIC
Manufacturer Part Number
GUX100
Series
For Standard Body
Material
Iron
Finish
Triple Coat Epoxy Coating
Back Type
Round
Body Type
Conduit Outlet Body
Hub Style
Threaded
Standards
UL Listed for Class I, Division 1 and 2, Groups B, C, D, Class II, Division 1 and 2, Groups E, F, G, and Class III
Body Style
X
For Use With
Threaded IMC
Thread Gender
Female
Cover Included
Yes
Connection Type
Threaded
Gasket Included
Yes
Hazardous Location
Yes
Compatible Conduit Trade Size
1 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPLETON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Appleton Electric GUX100 is a GU-series, X-style conduit outlet body made of iron with a triple-coat epoxy finish. It has a 1-inch trade size, a 19-cubic-inch body capacity, and threaded female hubs. This UL-listed unit is suitable for hazardous locations and includes a cover and gasket.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the Appleton Electric GUX100 conduit outlet body used for?

The Appleton Electric GUX100 is an X-style conduit outlet body used in industrial electrical systems to provide a junction point for pulling, splicing, or routing conductors. It is suitable for hazardous locations classified as Class I, Division 1 and 2, Groups B, C, D, Class II, Division 1 and 2, Groups E, F, G, and Class III.

What are the specifications of the Appleton Electric GUX100?

The GUX100 is a GU-series iron conduit outlet body with a 1-inch trade size, 19-cubic-inch body capacity, and threaded female hubs. It features a triple-coat epoxy finish, round back type, and includes a cover and gasket. It is UL listed for hazardous locations and compatible with threaded IMC.

Where to buy the Appleton Electric GUX100 worldwide?

3G Electric supplies the Appleton Electric GUX100 conduit outlet body worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this UL-listed unit to any international destination.

How to install the Appleton Electric GUX100 conduit outlet body?

Install the GUX100 by threading it onto threaded IMC conduit using the female hubs. Ensure the gasket is seated properly before securing the cover. Follow standard electrical practices for hazardous locations, including proper sealing and bonding. Always consult the manufacturer's instructions and local codes for safe installation.

Used in

Common applications for APPLETON ELECTRIC
Oil and gas refineries — Appleton Electric EDSC21MC2 manual motor switch for controlling pumps in Class I, Division 1 areas
Chemical processing plants — Appleton Electric AEAB13420C hazardous location circuit breaker for motor protection in volatile environments
Pharmaceutical manufacturing — Appleton Electric FSK-1VDR weatherproof cover for duplex receptacles in washdown zones
Wastewater treatment facilities — Appleton Electric UNY250R-A aluminum conduit union for corrosion-resistant connections
Mining operations — Appleton Electric EDSC277-SA tandem 2-gang box for junction points in hazardous dust locations
Food and beverage processing — Appleton Electric JBK-75 iron cover for conduit access fittings in wet or dusty areas

APPLETON ELECTRIC Products

3G Electric supplies APPLETON ELECTRIC x, xat and xtf round body - cross type. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
