Honeywell 3G-OTH-67520 — Technical Specifications
The Honeywell M8185D1006/U is a fail-safe rotary actuator with spring return for dampers and valves, featuring a double-ended shaft, 160° stroke, and clockwise rotation. It operates on 24V AC with a 20W power rating, is hardwired, and is compatible with building automation systems.
Technical Specifications
| Parameter | Value |
|---|---|
| AC | 24V |
| Type | On/Off, Spring Return, 60 in-lb, Hardwired, NEMA 3 / IP54 |
| Brand | HONEYWELL |
| Shaft Type | Double-Ended |
| Power Rating | 20W |
| Input Voltage | 24V AC |
| Stroke Degree | 160° |
| Shaft Rotation | CW |
| Manufacturer Part Number | M8185D1006/U |
| Auxiliary Switch Included | No |
| Electrical Connection Type | Hardwired |
| For Use With Building Automation Systems | Building Automation System Compatible |
