SNAP-TITEH Series Hydraulic Quick-Connect Coupling Plugs

SNAP-TITE Hydraulic Quick Connect Hose Coupling: 1 in, 316 Stainless Steel

The SNAP-TITE H Series Hydraulic Quick-Connect Coupling Plug (SKU 20LG34, MPN SPHN16-16F) is a 1-inch coupling with 1"-11-1/2 thread size, constructed from 316 stainless steel with a nitrile seal. This product is a…

SKU 3G-OTH-456980

Brand

SNAP-TITE

Item

Hydraulic Quick Connect Hose Coupling: 1 in, 316 Stainless Steel

Technical Specifications

SNAP-TITE

Manufacturer Part Number

SPHN16-16F

Thread Size

1"-11-1/2

Seal Material

Nitrile

Stainless Steel

316

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

SNAP-TITE Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the SNAP-TITE H Series hydraulic quick-connect coupling plug used for?

The SNAP-TITE H Series plug is used in hydraulic systems to enable rapid connection and disconnection of fluid lines without tools. It is ideal for industrial applications requiring a reliable, leak-resistant seal, such as in mobile equipment, machine tools, and high-pressure hydraulic circuits.

What are the specifications of the SNAP-TITE SPHN16-16F coupling?

The SNAP-TITE SPHN16-16F is a 1-inch hydraulic quick-connect coupling plug with a 1"-11-1/2 thread size. It is constructed from 316 stainless steel with a nitrile seal. This H Series component is designed for high-pressure hydraulic systems and is a genuine SNAP-TITE part.

Where to buy SNAP-TITE hydraulic couplings worldwide?

3G Electric supplies genuine SNAP-TITE hydraulic couplings like the SPHN16-16F to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us to order this 316 stainless steel quick-connect plug for your hydraulic system.

How to install a SNAP-TITE quick-connect coupling plug?

To install the SNAP-TITE H Series plug, ensure the mating coupler and threads are clean and undamaged. Apply compatible thread sealant to the 1"-11-1/2 male threads, then tighten to the manufacturer's recommended torque. Always depressurize the system before connection or disconnection to avoid fluid injection injury.
