SNAP-TITEH Series Hydraulic Quick-Connect Coupling Plugs

SNAP-TITE Hydraulic Quick Connect Hose Coupling: 3/4 in, Steel, 102.2 lpm Max. Flow Rate

SKU 3G-OTH-457011

Brand

SNAP-TITE

Item

Hydraulic Quick Connect Hose Coupling: 3/4 in, Steel, 102.2 lpm Max. Flow Rate

Technical Specifications

SNAP-TITE

Manufacturer Part Number

PHN12-12M

Type

Steel, 102.2 lpm Max. Flow Rate, Buna, MNPT

Thread Size

3/4"-14

Seal Material

Buna

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

SNAP-TITE Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SNAP-TITE H Series Hydraulic Quick-Connect Coupling Plug (MPN PHN12-12M) is a steel-bodied coupling with a 3/4"-14 MNPT thread, Buna seal material, and a maximum flow rate of 102.2 lpm. 3G Electric interprets demand and delivers this genuine industrial component across 14 departments, with specialist depth in pumps and controls as an authorised distributor.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a SNAP-TITE H Series hydraulic quick-connect coupling plug used for?

The SNAP-TITE H Series plug (MPN PHN12-12M) is used in hydraulic systems to enable rapid connection and disconnection of fluid lines under pressure. It is common in mobile equipment, industrial machinery, and oilfield applications where reliable, leak-free coupling is required.

What are the specifications of the SNAP-TITE PHN12-12M coupling?

The SNAP-TITE PHN12-12M is a steel-bodied hydraulic quick-connect coupling plug with a 3/4"-14 MNPT thread, Buna seal material, and a maximum flow rate of 102.2 lpm. It is part of the H Series and designed for high-pressure hydraulic circuits.

Where to buy SNAP-TITE hydraulic couplings in worldwide?

3G Electric supplies and delivers genuine SNAP-TITE hydraulic couplings worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on the PHN12-12M or other SNAP-TITE H Series components.

How to select the right SNAP-TITE quick-connect coupling?

Select a SNAP-TITE coupling based on thread size, seal material, and flow rate. For the PHN12-12M, use a 3/4"-14 MNPT port and Buna-compatible fluid. Ensure the coupling body material (steel) matches system pressure requirements. Consult a SNAP-TITE catalog for full specifications.

Used in

Common applications for SNAP-TITE

Hydraulic tool maintenance — SNAP-TITE IH Series couplings (e.g., VIHC6-6F) for quick hose connections in hydraulic wrenches and crimpers.

Agricultural equipment — SNAP-TITE IH Series couplings (e.g., VIHC4-4M) for hydraulic lines on tractors and harvesters.

Construction machinery — SNAP-TITE IH Series couplings (e.g., VIHC8-8F) for hydraulic circuits on excavators and loaders.

Industrial fluid power systems — SNAP-TITE IH Series couplings (e.g., VIHC12-12F) for connecting hydraulic power units to actuators.

Mobile hydraulic systems — SNAP-TITE IH Series couplings (e.g., VIHC6-6M) for quick disconnects on forklifts and aerial lifts.
