SCHNEIDER Overload Relay: Electronic Protection, 3 Poles, 1NO/1NC - IEC Electronic Overload Relays
SCHNEIDERIEC Electronic Overload Relays

SCHNEIDER Overload Relay: Electronic Protection, 3 Poles, 1NO/1NC

The SCHNEIDER Overload Relay: Electronic Protection (MPN LR9G115) is an IEC electronic overload relay with a Trip Class of 5E/30E, designed for use with TeSys Giga contactors (28 to 115 Amp Models) and the TeSys…

SKU 3G-OTH-45073

Brand
SCHNEIDER
Item
Overload Relay: Electronic Protection, 3 Poles, 1NO/1NC
Category
IEC Electronic Overload Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SCHNEIDER
Manufacturer Part Number
LR9G115
Type
1NO/1NC, Phase Loss Sensitivity
Poles
3
Trip Class
5E/30E
Compatible Contactors
TeSys Giga (28 to 115 Amp Models)
Auxiliary Contact Form
1NO/1NC
Maximum Voltage Rating
1000V AC
Phase Loss Sensitivity
Yes
Thermal Units Required
Not Applicable to Electronic Type Overload Relays
Terminal Connection Type
Wire Leads
Compatible Contactor Series
TeSys
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SCHNEIDER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SCHNEIDER Overload Relay: Electronic Protection (MPN LR9G115) is an IEC electronic overload relay with a Trip Class of 5E/30E, designed for use with TeSys Giga contactors (28 to 115 Amp Models) and the TeSys contactor series. It features a 1NO/1NC auxiliary contact form, wire leads terminal connection, a maximum voltage rating of 1000V AC, and phase loss sensitivity. Thermal units are not applicable to this electronic type overload relay.
