PIC GAUGES Industrial Pressure Gauge: 0 psi to 3,000 psi, 2 1/2 in Dial, 1/4 in NPT Male - U-Clamp Panel-Mount with Copper Wetted Parts
PIC GAUGESU-Clamp Panel-Mount with Copper Wetted Parts

PIC GAUGES Industrial Pressure Gauge: 0 psi to 3,000 psi, 2 1/2 in Dial, 1/4 in NPT Male

The PIC GAUGES Industrial Pressure Gauge (SKU 54XN94) is a U-Clamp Panel-Mount gauge with a 2 1/2 in dial and 1/4 in NPT male connection, measuring 0 psi to 3,000 psi. It features brass/copper wetted parts and an…

SKU 3G-OTH-175259

Brand
PIC GAUGES
Item
Industrial Pressure Gauge: 0 psi to 3,000 psi, 2 1/2 in Dial, 1/4 in NPT Male
Category
U-Clamp Panel-Mount with Copper Wetted Parts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

PIC GAUGES
Manufacturer Part Number
103D-254P
Type
103D, 103D
Dial
2 1/2 in
Accuracy
±3-2-3%
NPT Male
1/4 in
Gauge Wetted Parts
Brass / Copper
Vibration Resistance Properties
None
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

PIC GAUGES Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The PIC GAUGES Industrial Pressure Gauge (SKU 54XN94) is a U-Clamp Panel-Mount gauge with a 2 1/2 in dial and 1/4 in NPT male connection, measuring 0 psi to 3,000 psi. It features brass/copper wetted parts and an accuracy of ±3-2-3%, with no vibration resistance properties.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is PIC GAUGES 103D-254P pressure gauge used for?

The PIC GAUGES 103D-254P industrial pressure gauge measures 0 psi to 3,000 psi in hydraulic, pneumatic, and process systems. Its brass/copper wetted parts suit non-corrosive fluids and gases. The U-clamp panel-mount design allows secure installation in control panels, pumps, and compressors across manufacturing and industrial facilities.

What are the specifications of PIC GAUGES 103D-254P?

This PIC GAUGES gauge has a 2 1/2 in dial, 1/4 in NPT male connection, and ±3-2-3% accuracy. It measures 0 psi to 3,000 psi with brass/copper wetted parts and no vibration resistance. The model is 103D-254P, part of the 103D series, designed for U-clamp panel mounting.

Where to buy PIC GAUGES 103D-254P worldwide?

3G Electric supplies the PIC GAUGES 103D-254P pressure gauge to customers worldwide. We handle full logistics, customs clearance, and delivery to your facility. As a global industrial solutions provider, we source and deliver this gauge along with related instrumentation from brands like Fluke and Siemens.

How to install a U-clamp panel-mount pressure gauge?

For the PIC GAUGES 103D-254P, mount the gauge through a panel cutout and secure it with the U-clamp from behind. Apply thread sealant to the 1/4 in NPT male connection and tighten to 20-30 ft-lb. Avoid over-torquing the brass fitting. Use a pressure snubber if pulsation is present, as this gauge has no vibration resistance.

Used in

Common applications for PIC GAUGES
Hydraulic system monitoring — PIC GAUGES 103D series panel-mount gauges for 0–3,000 psi oil pressure indication
Corrosive chemical processing — PIC GAUGES 301L series with 316 SS diaphragm seal for 0–600 psi acid line measurement
Pneumatic control panels — PIC GAUGES 104D series front-flange gauges for 0–600 psi compressed air systems
Viscous fluid transfer — PIC GAUGES 301L series with glycerin-filled seal for 0–200 psi slurry or polymer lines
Steam or condensate lines — PIC GAUGES 301L series with 316 SS mini-seal for 0–160 psi steam pressure monitoring
Water treatment plant — PIC GAUGES 103D series U-clamp gauges for 0–1,000 psi pump discharge pressure
