PIC GAUGES Pressure Gauge with Diaphragm Seal: 30 in Hg to 0 in Hg, 301L/3JJJ, 2 1/2 in Dial
The PIC GAUGES Pressure Gauge with Diaphragm Seal is a low-pressure dial gauge with a 316 SS mini-seal, featuring a 2 1/2 in dial and bottom connection. It has a pressure range of 30 in Hg to 0 in Hg, an accuracy of…
SKU 3G-OTH-174755
Need installation or engineering help?
Ask a question
Product Description
The PIC GAUGES Pressure Gauge with Diaphragm Seal is a low-pressure dial gauge with a 316 SS mini-seal, featuring a 2 1/2 in dial and bottom connection. It has a pressure range of 30 in Hg to 0 in Hg, an accuracy of ±2-1-2%, and a glycerin seal fill liquid. The gauge wetted parts are stainless steel, and the seal lower housing is made of 316 stainless steel, with no gauge case liquid.
Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.
Frequently Asked Questions
What is a PIC GAUGES pressure gauge with diaphragm seal used for?
This PIC GAUGES pressure gauge with diaphragm seal is used for low-pressure vacuum measurement from 30 in Hg to 0 in Hg in industrial processes. The 316 stainless steel mini-seal isolates the gauge from corrosive media, making it suitable for chemical, petrochemical, and pharmaceutical applications where accuracy of ±2-1-2% is required.
What are the specifications of the PIC GAUGES 301L254A/3JJJ100?
The PIC GAUGES 301L254A/3JJJ100 has a 2 1/2 in dial, bottom connection, pressure range of 30 in Hg to 0 in Hg, accuracy of ±2-1-2%, and a glycerin seal fill liquid. The seal lower housing is 316 stainless steel, gauge wetted parts are stainless steel, and there is no gauge case liquid.
Where to buy a PIC GAUGES pressure gauge with diaphragm seal worldwide?
3G Electric supplies the PIC GAUGES pressure gauge with diaphragm seal worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this 301L254A/3JJJ100 gauge to your facility. Contact us for a quote and delivery lead time to your location.
How to install a PIC GAUGES pressure gauge with diaphragm seal?
Install the PIC GAUGES pressure gauge with diaphragm seal by mounting it with the bottom connection aligned vertically. Ensure the process connection is clean and use appropriate thread sealant. Avoid over-torquing the 316 stainless steel seal housing. The glycerin fill is factory-sealed; do not open the fill port.
