LEGRIS Compression Fitting Elbow: 12 mm OD x 1/4 in Pipe Fitting Size, Compression x MBSPT
The LEGRIS Compression Fitting Elbow is a standard sleeve brass compression fitting with a 12 mm OD tube size and 1/4 in pipe fitting size, configured as Compression x MBSPT. Supplied in a 10-pack (MPN 0109 12 13)…
SKU 3G-OTH-482246
Need installation or engineering help?
Ask a question
Product Description
The LEGRIS Compression Fitting Elbow is a standard sleeve brass compression fitting with a 12 mm OD tube size and 1/4 in pipe fitting size, configured as Compression x MBSPT. Supplied in a 10-pack (MPN 0109 12 13), this fitting is part of our broad industrial offering across 14 departments, with specialist depth in combustion, pumps, and controls as an authorised distributor for brands like LEGRIS, Schneider, ABB, and Siemens.
Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.
Frequently Asked Questions
What is a LEGRIS compression fitting elbow used for?
A LEGRIS compression fitting elbow connects 12 mm OD tubing to 1/4 in BSPT threaded ports at a 90° angle, creating a leak-tight seal in pneumatic, hydraulic, and fluid-handling systems across industrial plants, machining lines, and process skids.
What are the specifications of the LEGRIS 0109 12 13 fitting?
The LEGRIS 0109 12 13 is a standard sleeve brass compression elbow with a 12 mm OD tube size and 1/4 in MBSPT thread. It is supplied as a 10-pack and is configured as Compression x MBSPT. 3G Electric supplies this fitting globally.
Where to buy LEGRIS compression fittings in worldwide?
3G Electric supplies LEGRIS compression fittings worldwide, handling full logistics and customs clearance. As a global industrial solutions provider, we source and deliver genuine LEGRIS parts like the 0109 12 13 elbow to any international destination.
How to install a LEGRIS compression fitting elbow?
To install a LEGRIS compression fitting elbow, slide the nut and sleeve onto the tube, insert the tube fully into the fitting body, then tighten the nut by hand followed by a wrench until the sleeve grips the tube. Avoid overtightening to prevent tube deformation.
Used in
Common applications for LEGRISLEGRIS Products
3G Electric supplies LEGRIS standard sleeve brass compression fittings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
