LEGRIS Compression Fitting Elbow: 10 mm OD x 10 mm OD Fitting Size, Compression x Compression
The LEGRIS Compression Fitting Elbow is a standard sleeve brass compression fitting with a 10 mm OD x 10 mm OD fitting size, configured as compression x compression. Supplied in a pack of 10 (MPN 0102 10 00), this…
SKU 3G-OTH-482096
Need installation or engineering help?
Ask a question
Product Description
The LEGRIS Compression Fitting Elbow is a standard sleeve brass compression fitting with a 10 mm OD x 10 mm OD fitting size, configured as compression x compression. Supplied in a pack of 10 (MPN 0102 10 00), this component is designed for joining tubing in industrial fluid systems.
Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.
Frequently Asked Questions
What is a LEGRIS compression fitting elbow used for?
A LEGRIS compression fitting elbow connects two 10 mm OD tubes at a 90° angle in industrial fluid systems. It uses a brass compression mechanism to create a leak-tight seal, commonly applied in pneumatic, hydraulic, and instrumentation lines where space constraints require a directional change.
What are the specifications of the LEGRIS 0102 10 00 fitting?
The LEGRIS 0102 10 00 is a standard sleeve brass compression fitting elbow. It has a 10 mm OD x 10 mm OD fitting size with compression x compression ends. Supplied in a pack of 10, it is designed for joining tubing in industrial fluid systems.
Where to buy LEGRIS compression fittings worldwide?
3G Electric supplies LEGRIS compression fittings worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver the LEGRIS 0102 10 00 elbow and other pneumatic components to your facility. Contact us for a quote and delivery timeline.
How to install a LEGRIS compression fitting elbow?
To install a LEGRIS compression fitting elbow, slide the nut and ferrule onto the 10 mm OD tube, insert the tube fully into the fitting body, then tighten the nut by hand followed by a wrench turn. Avoid overtightening to prevent tube deformation. Always verify the tube is fully seated before pressurizing.
