HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #8-32 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #8-32 Thread Size

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #8-32 Thread Size, 100 PK (MPN A3585-2CNW164). These 18-8 stainless steel inserts feature a Dry Film Lubricant finish, coarse right-hand threads, and a…

SKU 3G-OTH-528838

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, #8-32 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A3585-2CNW164
Type
Screw-Locking, #8-32 Thread Size, 100 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Dry Film Lubricant
Thread Type
Coarse
STI Tap Size
#8-32
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #8-32 Thread Size, 100 PK (MPN A3585-2CNW164). These 18-8 stainless steel inserts feature a Dry Film Lubricant finish, coarse right-hand threads, and a tensile strength of 200,000 to 250,000 psi. Designed for use in metal with an STI Tap Size of #8-32, they provide reliable thread repair and locking in inch-system applications.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a HELI-COIL screw-locking tanged helical insert used for?

A HELI-COIL screw-locking tanged helical insert repairs or reinforces stripped internal threads in metal. The screw-locking feature resists vibration loosening, making it ideal for engines, pumps, and industrial machinery where fastener retention is critical.

What are the specifications of the HELI-COIL A3585-2CNW164 insert?

This HELI-COIL insert has a #8-32 coarse thread, 18-8 stainless steel construction, and a tensile strength of 200,000 to 250,000 psi. It uses a Dry Film Lubricant finish, requires an STI tap size of #8-32, and comes in a 100-piece pack.

Where to buy HELI-COIL helical inserts in worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial sourcing partner, we handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on the A3585-2CNW164 or other thread repair inserts.

How to install a HELI-COIL tanged helical insert?

To install, drill out the damaged thread to the specified size, tap the hole using the correct STI tap, then insert the HELI-COIL using a tang drive tool. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for best results.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
