HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, M5-0.80 Thread Size
The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert with M5-0.80 thread size, coarse thread, and right-hand direction. Made from 18-8 material with a dry film lubricant finish, it offers tensile…
SKU 3G-OTH-528815
Need installation or engineering help?
Ask a question
Product Description
The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert with M5-0.80 thread size, coarse thread, and right-hand direction. Made from 18-8 material with a dry film lubricant finish, it offers tensile strength of 200,000 to 250,000 psi and is compatible with metal. Supplied in a 1,000 PK, this metric insert uses an STI tap size of M5-0.80.
Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.
Frequently Asked Questions
What is a HELI-COIL helical insert used for?
A HELI-COIL helical insert repairs or reinforces threads in metal. This screw-locking, tanged tang-style insert with M5-0.80 thread size provides strong, wear-resistant threads in aluminum, cast iron, or steel components, preventing thread stripping under high loads.
What are the specifications of the HELI-COIL 4184-5CNW075S insert?
This HELI-COIL insert has an M5-0.80 coarse thread, right-hand direction, and 18-8 material grade. It offers tensile strength of 200,000 to 250,000 psi, uses an STI tap size of M5-0.80, and comes in a 1,000 PK with a dry film lubricant finish.
Where to buy HELI-COIL helical inserts worldwide?
3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this M5-0.80 screw-locking insert to your facility. Contact us for availability and lead time.
How to install a tanged tang-style helical insert?
To install a tanged tang-style helical insert, drill to the specified STI tap size (M5-0.80), tap the hole, then use a tang insertion tool to wind the insert into place. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for best results.
