HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 3/4"-16 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 3/4"-16 Thread Size

The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert with a 3/4"-16 fine thread, 3/4 in overall length, and a tensile strength of 200,000 to 250,000 psi. Made from 18-8 material, it is designed…

SKU 3G-OTH-528866

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, 3/4"-16 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
3591-12CN750
Type
Screw-Locking
Overall Lg
3/4 in
Tensile Strength
200,000 to 250,000 psi
Finish Type
Plain
Thread Size
3/4"-16
Thread Type
Fine
STI Tap Size
3/4"-16
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert with a 3/4"-16 fine thread, 3/4 in overall length, and a tensile strength of 200,000 to 250,000 psi. Made from 18-8 material, it is designed for right-hand threading in metal and requires an STI tap size of 3/4"-16.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threads in metal. This screw-locking, tanged tang-style insert with 3/4"-16 fine thread provides strong, wear-resistant threads in applications like automotive, aerospace, and industrial machinery, with tensile strength of 200,000 to 250,000 psi.

What are the specifications of the HELI-COIL 3591-12CN750 insert?

The HELI-COIL 3591-12CN750 is a screw-locking, tanged tang-style helical insert with 3/4"-16 fine thread, 3/4 in overall length, and 18-8 material grade. It has right-hand thread direction, requires an STI tap size of 3/4"-16, and offers tensile strength of 200,000 to 250,000 psi.

Where to buy HELI-COIL helical inserts worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this 3/4"-16 screw-locking insert to your facility. Contact us for availability and lead time on this HELI-COIL part.

How to install a tanged tang-style helical insert?

To install a HELI-COIL tanged tang-style insert, drill to the specified size, tap with the correct STI tap (3/4"-16 for this insert), then use a tang-style installation tool to wind the insert into the tapped hole. After installation, break off the tang for a flush finish. Always follow manufacturer instructions.
