HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 1 1/4"-7 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, 1 1/4"-7 Thread Size

The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert made from 18-8 stainless steel with a plain finish. It features a 1 1/4"-7 coarse right-hand thread, an STI tap size of 1-1/8"-7, and a…

SKU 3G-OTH-529001

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, 1 1/4"-7 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
3585-20CN1250
Type
Screw-Locking, Stainless Steel
Tensile Strength
200,000 to 250,000 psi
Finish Type
Plain
Thread Size
1 1/4"-7
Thread Type
Coarse
STI Tap Size
1-1/8"-7
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a tanged tang-style, screw-locking insert made from 18-8 stainless steel with a plain finish. It features a 1 1/4"-7 coarse right-hand thread, an STI tap size of 1-1/8"-7, and a tensile strength of 200,000 to 250,000 psi, designed for use with metal materials.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces tapped threads in metal. This screw-locking tanged tang style, with 1 1/4"-7 coarse thread, provides strong, wear-resistant threads in applications like engine blocks or industrial equipment, preventing thread stripping under high loads.

What are the specifications of the HELI-COIL 3585-20CN1250?

This HELI-COIL insert has a 1 1/4"-7 coarse right-hand thread, STI tap size 1-1/8"-7, and tensile strength 200,000 to 250,000 psi. It is made from 18-8 stainless steel with a plain finish, designed for metal materials. The manufacturer part number is 3585-20CN1250.

Where to buy HELI-COIL helical inserts worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this 1 1/4"-7 screw-locking insert to your facility. Contact us for availability and lead time on this part.

How to install a HELI-COIL tanged helical insert?

Installation requires drilling to the specified STI tap size (1-1/8"-7 for this insert), tapping the hole, then using a tang drive tool to insert the coil. After installation, break off the tang. Always follow HELI-COIL's generic instructions for proper thread engagement and torque.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
