EZO Ball Thrust Bearing: F6-14M, 6 mm Bore Dia, 14 mm Outside Dia, 5 mm Overall Wd - Separable Grooved-Race Ball Thrust Bearings
EZOSeparable Grooved-Race Ball Thrust Bearings

EZO Ball Thrust Bearing: F6-14M, 6 mm Bore Dia, 14 mm Outside Dia, 5 mm Overall Wd

The EZO F6-14M is a separable grooved-race ball thrust bearing from the FM Series, featuring a 6 mm bore diameter, 14 mm outside diameter, and 5 mm overall width. It is constructed with SUJ2 ball material grade and…

SKU 3G-OTH-108453

Brand
EZO
Item
Ball Thrust Bearing: F6-14M, 6 mm Bore Dia, 14 mm Outside Dia, 5 mm Overall Wd
Category
Separable Grooved-Race Ball Thrust Bearings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EZO
Manufacturer Part Number
F6-14M
Type
Grooved, Steel
Bore Dia
6 mm
Overall Wd
5 mm
Outside Dia
14 mm
Maximum Speed
12,000 RPM Grease
Bearing Series
FM Series
Ball Material Grade
SUJ2
Thrust Bearing Type
Separable Ball Thrust Bearing
System of Measurement
Metric
Bearing Industry Number
F6-14M
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EZO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EZO F6-14M is a separable grooved-race ball thrust bearing from the FM Series, featuring a 6 mm bore diameter, 14 mm outside diameter, and 5 mm overall width. It is constructed with SUJ2 ball material grade and has a maximum speed of 12,000 RPM with grease lubrication.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Used in

Common applications for EZO
Medical instruments — EZO stainless steel miniature ball bearings (e.g., 692XHZZP6MC3AF2) in dental handpieces and surgical tools
Precision encoders — EZO flanged bearings (e.g., F685HZZP6MC3SRL) for optical encoder shafts requiring axial location
Small electric motors — EZO radial ball bearings (e.g., 686HZZP6MC3SRL) in miniature DC motors and servo actuators
Instrumentation — EZO high-clearance bearings (e.g., SFR2-5 A3MC3AF2) in flow meters and pressure sensors
Robotics — EZO inch-series bearings (e.g., SR188ZZA3MC3SRL) in compact joint modules and end-effectors
Aerospace actuators — EZO corrosion-resistant bearings (e.g., SFR166ZZA3MC3AF2) in control surface linkages

EZO Products

3G Electric supplies EZO separable grooved-race ball thrust bearings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
