Dayton In-Line Duct Fan: 571 cfm Max., 8 in Duct, 111.9 W, 120V AC, 1 Ph, IP54 - General Purpose Inline Duct Fans
DaytonGeneral Purpose Inline Duct Fans

Dayton In-Line Duct Fan: 571 cfm Max., 8 in Duct, 111.9 W, 120V AC, 1 Ph, IP54

The Dayton In-Line Duct Fan (SKU 450Z11, MPN 23227) is a general-purpose inline duct fan with a steel housing and IP54 rating. It delivers a maximum airflow of 571 cfm at 0.000 in SP, operates on 120V AC single-phase…

SKU 3G-OTH-79263

Brand
Dayton
Item
In-Line Duct Fan: 571 cfm Max., 8 in Duct, 111.9 W, 120V AC, 1 Ph, IP54
Category
General Purpose Inline Duct Fans
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
23227
Includes
Mounting Bracket
Number of Speeds
1
Nameplate Voltage
120V AC
Speed Controllable
Yes
High-Efficiency Motor
No
High-Efficiency Motor Broad
Standard-Efficiency Motor
Airflow @ 0.000 in SP - Range
500 to 749 cfm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton In-Line Duct Fan (SKU 450Z11, MPN 23227) is a general-purpose inline duct fan with a steel housing and IP54 rating. It delivers a maximum airflow of 571 cfm at 0.000 in SP, operates on 120V AC single-phase power at 111.9 W, and includes a mounting bracket. This single-speed fan is speed controllable and features a standard-efficiency motor.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the Dayton In-Line Duct Fan used for?

The Dayton In-Line Duct Fan (MPN 23227) is used for general-purpose ventilation in ducted systems, moving up to 571 cfm of air at 0.000 in SP. It suits exhaust or supply applications in commercial and industrial settings where a compact, steel-housed fan with IP54 protection is needed.

What are the specifications of the Dayton In-Line Duct Fan 23227?

This Dayton fan delivers 571 cfm maximum airflow, operates on 120V AC single-phase at 111.9 W, and fits 8 in duct. It is single-speed, speed controllable, with a standard-efficiency motor and IP54-rated steel housing. Includes a mounting bracket.

Where to buy the Dayton In-Line Duct Fan 23227 worldwide?

3G Electric supplies the Dayton In-Line Duct Fan (MPN 23227) to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us to order this fan for your ventilation project.

How to install the Dayton In-Line Duct Fan?

Mount the fan using the included bracket in a straight section of 8 in ductwork, ensuring airflow direction matches the arrow on the housing. Connect 120V AC single-phase power to the terminal box. For speed control, use a compatible fan speed controller. Always follow local electrical codes.
