Dayton In-Line Duct Fan: 213 cfm Max., 6 in Duct, 37.3 W, 120V AC, 1 Ph, IP54 - General Purpose Inline Duct Fans
DaytonGeneral Purpose Inline Duct Fans

Dayton In-Line Duct Fan: 213 cfm Max., 6 in Duct, 37.3 W, 120V AC, 1 Ph, IP54

The Dayton In-Line Duct Fan (SKU 450Z08, MPN 23224) is a general-purpose inline duct fan with a 6-inch duct, a maximum airflow of 213 cfm, and a nameplate voltage of 120V AC. It operates as a single-speed unit with a…

SKU 3G-OTH-78934

Brand
Dayton
Item
In-Line Duct Fan: 213 cfm Max., 6 in Duct, 37.3 W, 120V AC, 1 Ph, IP54
Category
General Purpose Inline Duct Fans
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
23224
Includes
Mounting Bracket
Number of Speeds
1
Nameplate Voltage
120V AC
Speed Controllable
Yes
High-Efficiency Motor
No
High-Efficiency Motor Broad
Standard-Efficiency Motor
Airflow @ 0.000 in SP - Range
0 to 249 cfm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton In-Line Duct Fan (SKU 450Z08, MPN 23224) is a general-purpose inline duct fan with a 6-inch duct, a maximum airflow of 213 cfm, and a nameplate voltage of 120V AC. It operates as a single-speed unit with a standard-efficiency motor, is speed controllable, and includes a mounting bracket. The fan features an IP54 rating and a steel construction.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the Dayton In-Line Duct Fan used for?

The Dayton In-Line Duct Fan is used for general-purpose ventilation in commercial or industrial duct systems. It moves air through 6-inch ducts at up to 213 cfm, making it suitable for exhaust or supply applications where moderate airflow and speed control are needed.

What are the specifications of the Dayton In-Line Duct Fan 23224?

The Dayton In-Line Duct Fan (MPN 23224) has a 6-inch duct, max airflow of 213 cfm, 120V AC single-phase power, 37.3 W, IP54 rating, and steel construction. It is a single-speed, standard-efficiency motor that is speed controllable and includes a mounting bracket.

Where to buy the Dayton In-Line Duct Fan worldwide?

You can source the Dayton In-Line Duct Fan through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this model.

How to install the Dayton In-Line Duct Fan?

Mount the fan using the included bracket in a secure, vibration-free location. Connect the 120V AC power supply to the fan's wiring, ensuring proper grounding. Use speed control if desired. Always follow local electrical codes and the manufacturer's installation manual for safe operation.
