CBMGas Valves & Regulation

CBM Timepurge ST 7800 A 1039

CBM Timepurge ST 7800 A 1039 is a 2-way ball valve with flange connections rated for 16 bar and DN25 mm, featuring a carbon steel ball and lever handle. Ideal for water distribution and industrial piping systems…

SKU 3G-CBM-06184

Also listed as: ROB 14012 · ROB-14012

Brand

CBM

Item

Timepurge ST 7800 A 1039

Local availability & support — the Philippines

Delivery: 5–8 business days door-to-door; Bureau of Customs clearance typically 2–4 business days.
Payment: Invoicing in PHP or USD. Bank transfer and corporate PO accepted.
Ships to: Manila, Quezon City, Cebu, Davao, Batangas

Technical Specifications

CBM

length lw

125 mm

connection

Fl/Fl

valve type

2-way ball valve with flange connections

handle type

Lever handle

ball material

Carbon steel DVGW

pressure rating pn

16 bar

nominal diameter dn

25 mm

Datasheet Content

KUGELHÄHNE | Manueller Betrieb BALL VALVES | manually operated                                                                                                                                                                                                                      KUGELHÄHNE | Manueller Betrieb BALL VALVES | manually operated


 DURCHGANGSKUGELHÄHNE MIT FLANSCHANSCHLUSS 2-WAY BALL
 VALVES WITH FLANGE CONNECTIONS                                                                                                                                    75        75                                                                                              DURCHGANGSKUGELHÄHNE MIT FLANSCHANSCHLUSS
                                                                                                                                                                                                                                                                                2-WAY BALL VALVES WITH FLANGE CONNECTIONS




KSL75B                 KSL75E                 KSL75F                 KSA75B                   KSN75B              KSN75E            KSN75F
                                                                                                                                                                             Datentabelle data table

KSN75B | Hebelgriff | Fl/Fl | Kugel Stahlguss DVGW Gas PN 16                                                                                                                   DN        LW      PN          L       MM       R          H              h    D           K    g        z         d       SW1        M      d1     d2      Gewicht       Artikel-Nr.
KSN75B | Lever handle | Fl/Fl | Ball carbon steel DVGW natural gas PN 16                                                                                                      (mm)       (mm)   (bar)       (mm)     (mm)    (mm)       (mm)        (mm)    (mm)     (mm)    (mm)               (mm)     (mm)             (mm)   (mm)
                                                                                                                                                                                                                                                                                                                                          Weight
                                                                                                                                                                                                                                                                                                                                            (kg)
                                                                                                                                                                                                                                                                                                                                                        Item number


                                                                                                                                                                               25         25     16         125      62,5    165        111,5         60     115      85      68       4         14       11        F05    50    6,6          3,220     ROB14002
                                                                                                                                                                               32         32     16         130       65     165        122,5         71     140     100      78       4         18       11        F05    50    6,6          4,500     ROB14004
                                                                                              Druck-Temperatur-Diagramm pressure-temperature-diagram
                                                                                                                                                                              40         40      16         140       70     185         134          77     150     110      88       4         18       14        F05   50     6,6          5,700     ROB14006
                                                                                                                                                                              50         50      16         150       75     185         142         85      165     125     102       4         18       14        F05   50     6,6          7,877     ROB14008
                                                                                                 bar                                                                          65         65      16         170       85     230        154,5        95      185     145     122       4         18       17        F07    70     9          12,100     ROB14010
                                                                                                  20                                                                           80         80     16         180      90,5    360        180,5       103,5    200     160     136       8         18       22        F07    70     9          15,500     3G-CBM-06184
                                                                                                                                                                              100        100     16         190       92     360         197         120     220     180     158       8         18       22        F10   102    11          22,600     ROB14014
                                                                                                                                                                              125        125     16         200       98     360         216         139     250     210     188       8         18       22        F10   102    11          30,400     ROB14016
                                                                                                  15
                                                                                                                                                                              150        142     16         210      100     556         236         158     285     240     212       8         22       27        F10   102    11          42,000     ROB14018

                                                                                                  10                                                                                                                     A
                                                                                                                                                                             Maßskizze measured sketch                                                                               Materialtabelle materials grid
                                                                                                   5

                                                                                                                                                                                                                                                                                           Nr.        Bezeichnung                Werkstoff                 Materialbezeichnung
                                                                                                   0                                                                                                                                                                                       No.        Description                Material                  Material description
                                                                                                       -20    0       20      40     60       80      100      120 °C                                                             
                                                                                                                                                                                                                                                                                           1          Gehäuse                    Sphäroguss                5.3103
                                                                                                             Gas EN13774                                                                                                                                                                              Body                       Nodular cast iron
                                                                                                                                                                                                                                         6
                                                                                                                                                                                                                                                                                           2          Kugel                      Stahlguss verchromt       1.0503
                                                                                                                                                                                                                                                                                                      Ball                       Cast steel (chromed)
                                                                                                                                                                                                                                                                                           3          Kugeldichtung              PTFE                      -
                                                                                                                                                                                                                                                                                                      Ball seal                  PTFE
                                                                                                                                                                                                                                                                                           4          Flansch / Nippel           Sphäroguss                5.3103
                                                                                                                                                                                                                                                                                                      Flange / nipple            Nodular cast iron
                                                                                                                                                                                                                                                                         ,
                                                                                                                                                                                                                                                                                           5          Schaltwelle                Edelstahl                 1.4104
                                                                                                                                                                                                                                                        L…

Technical Documents

(2)

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

CBM Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

Where can I buy the CBM Timepurge ST 7800 A 1039 ball valve in the Philippines?

3G Electric Philippines supplies the CBM Timepurge ST 7800 A 1039 ball valve for delivery to Manila and Quezon City. We handle Bureau of Customs documentation and logistics. Contact us for availability and quotation on this DN25 mm, 16 bar rated 2-way ball valve.

What is the lead time for the CBM Timepurge ST 7800 A 1039 in the Philippines?

Lead time varies based on availability. Contact 3G Electric Philippines for current delivery schedules. We source and ship industrial valves to food processing, packaging, and power generation facilities across CALABARZON with full customs support.

What are the key specifications of the CBM Timepurge ST 7800 A 1039?

The CBM Timepurge ST 7800 A 1039 is a 2-way ball valve with flange connections (Fl/Fl), DN25 mm nominal diameter, 16 bar pressure rating, carbon steel DVGW ball, and lever handle. Body length is 125 mm, ideal for water distribution and industrial shutoff applications.

Used in

Common applications for CBM

Industrial boilers — CBM circulation pumps (mod. CM 30W) and solenoid valves (ELV series) for heating-loop control and pump staging.

Burner systems — CBM oil nozzles (FLU atomizer types), electrodes (ELC 200 mm), and solenoid coils (ELV 230V AC) for combustion ignition and flame supervision.

Plant maintenance and retrofit — CBM cable glands (CLI M25), motor couplings (ACC type D), and small-radius fittings (RAC 90°) for equipment reconfiguration and sensor integration.

Boiler water treatment — CBM chlorine test kits (DET free+combined) for feedwater and circulating-water quality monitoring in closed-loop systems.

Pump and motor assembly — CBM couplings, fittings, and cable glands for assembly and rewinding of industrial motors, circulation pumps, and auxiliary equipment.

CBM Products

3G Electric supplies CBM gas valves & regulation. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
