ELVSolenoid Valves

ELV Steam solenoid valve D 1"

The ELV steam solenoid valve with 1" connection controls steam flow in industrial heating and process systems. It operates across 0.5 to 10 bar with a 25 mm passage diameter and Cv value of 13.2, making it suitable…

SKU 3G-CBM-03265

Also listed as: ELV 35008 · ELV-35008

Brand

ELV

Item

Steam solenoid valve D 1"

Local availability & support — the Philippines

Delivery: 5–8 business days door-to-door; Bureau of Customs clearance typically 2–4 business days.
Payment: Invoicing in PHP or USD. Bank transfer and corporate PO accepted.
Ships to: Manila, Quezon City, Cebu, Davao, Batangas

Technical Specifications

ELV

fluid

steam

cv value

13.2

connection

1"

pressure max

10 bar

passage diameter

25 mm

operating pressure

0.5 ~ 10 bar

fluid viscosity max

50 CST

pressure differential max

25 bar

Datasheet Content

Electrovannes bronze NF vapeur                                                    Code

      Electrovanne vapeur 3/8”                                                                           ELV35002

      Electrovanne vapeur 1/2”                                                                           ELV35004

      Electrovanne vapeur 3/4”                                                                           ELV35006

      Electrovanne vapeur 1”                                                                             3G-CBM-03265

      Electrovanne vapeur 1”1/4                                                                          ELV35010

      Electrovanne vapeur 1”1/2                                                                          ELV35012

      Caractéristiques techniques
                  Modèle             ELV35002   ELV35004   ELV35006     3G-CBM-03265       ELV35010   ELV35012    ELV35014
      Diamètre Raccord                3/8”       1/2”       3/4”           1”          1”1/4      1”1/2         2”
      Diamètre passage               15mm       15mm       20mm          25mm          35mm       35mm         50mm
      Pression différentielle max.     25         25         25            25            25         25          25
      Valeur CV                        4.5        4.5        9.3          13.2           16         26          48
      Dim. A mm                        75         75         85           100           120        120         150
      Dim. C mm                       129        129        141           148           168        168         190
      Viscosité fluide                                             Moins de 50 CST
      Fluide                                                             Vapeur
      Pression fonctionnement                                         0.5 ~ 10 bar
      Pression maxi                                                      10 bar
      Température maxi                                                5°C ~ 180°C
      Tension                                                      +/- 10% - AC230V
      Matériel corps                                                     Bronze
      Membrane                                                            Teflon
      Mode opération                                                  Action directe
      Type                                                        Normalement fermée

      PIÈCES DE RECHANGES POUR VANNES
                  Modèle             ELV35002   ELV35004   ELV35006     3G-CBM-03265       ELV35010   ELV35012    ELV35014
      Référence bobine 220 V         ELV80515   ELV80515   ELV80515     ELV80515       ELV80515   ELV80515    ELV80515
      Référence bobine 110 V            -          -          -             -             -          -           -
      Référence bobine AC 48 V          -          -          -             -             -          -           -
      Référence bobine AC 24 V          -          -          -             -             -          -           -
      Référence bobine AC 12 V          -          -          -             -             -          -           -
      Référence bobine DC 24 V       ELV81515   ELV81515   ELV81515     ELV81515       ELV81515   ELV81515    ELV81515
      Référence bobine DC 12 V       ELV81530   ELV81530   ELV81530     ELV81530       ELV81530   ELV81530    ELV81530
      Référence membrane NBR            -          -          -             -             -          -           -
      Référence membrane EPDM           -          -          -             -             -          -           -
      Référence membrane VITON          -          -          -             -             -          -           -

254
BRASS STREAM VALVES
2/2-Way Pilot Operated Piston Solenoid Valve . Normally closed

                                                                 1/4
2/2-Way Pilot Operated Piston Solenoid Valve . Normally closed

                                                     ELV35004

                                                     ELV35006

                                                     3G-CBM-03265

                                                     ELV35010

                                                      ELV35012

                                                                 2/4
                              1/4

        INOX STREAM VALVES
2/2-Way Pilot Operated Piston Solenoid Valve . Normally closed

                                                     ELV40002

                                                     ELV40004

                                                     ELV40006

                                                     ELV40008

                                                                 3/4
2/2-Way Pilot Operated Piston Solenoid Valve . Normally closed

                                                                 4/4

Technical Documents

(2)

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

ELV Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

Where can I buy the ELV35008 steam solenoid valve in the Philippines?

3G Electric Philippines stocks and supplies the ELV35008 solenoid valve with delivery to Manila and Quezon City. We handle all logistics, customs clearance, and Bureau of Customs documentation for Philippine imports. Contact us for availability and lead-time confirmation.

What is the lead time for the ELV35008 steam solenoid valve to the Philippines?

Lead times depend on origin and current stock. 3G Electric arranges logistics and manages Philippine customs entry. Standard lead time on request — contact us with your project timeline for a confirmed delivery date.

Is the ELV35008 suitable for high-pressure steam applications?

The ELV35008 operates from 0.5 to 10 bar and handles a maximum pressure differential of 25 bar. With a Cv value of 13.2 and 25 mm passage diameter, it is rated for medium-flow steam control in industrial heating and process systems up to 10 bar.
