Dwyer Surface temperature sensor TE-SNW-C

Dwyer TE-SNW-C is a surface temperature sensor for industrial pipe monitoring, offering thermistance or RTD measurement with DIN Class A accuracy of ±0.15°C. Operating from -35.5 to +115.5°C, it mounts on 5 to 15 cm…

SKU 3G-CBM-02315

Also listed as: DWY 50006 · DWY-50006

Brand

Dwyer

Item

Surface temperature sensor TE-SNW-C

Local availability & support — the Philippines

Delivery: 5–8 business days door-to-door; Bureau of Customs clearance typically 2–4 business days.
Payment: Invoicing in PHP or USD. Bank transfer and corporate PO accepted.
Ships to: Manila, Quezon City, Cebu, Davao, Batangas

Technical Specifications

Dwyer

sensor type

Thermistance 10K or RTD

accuracy rtd

DIN Classe A ±0.15°C @ 0°C

housing material

Polycarbonate UL 94 V-0 NEMA 3R

pipe diameter range

5 to 15 cm

accuracy thermistance

±0.2°C @ 25°C

operating temperature limits

-35.5 to +115.5°C

Datasheet Content

Série
   TE-SNW             Capteurs de température de surface résistants aux intempéries
                      Conception avec Bride, Couvercle Dévissable, Tailles de Conduite de 5 à 15 cm
                                                                                                   3-3/8                                                     3-1/4
                                                                                                  [84.86]                                                   [82.38]
                                                                                                   1-1/2                                                       1 [25.97]
                                                                                                  [38.10]


                                                                                                                 FITS 2
                                                                                                               TO 6˝ PIPE



                                                                                                                                                                       2 X PG11
                                                                                                                                                                      KNOCKOUTS
                                                                                                                                                                    2 X PG16
                                                                                                                                                                   KNOCKOUTS

La Série TE-SNW Capteur de Température de Surface mesure sans intrusion la                        SPÉCIFICATIONS
température de service dans les boucles d’eau chaudes et froides dans les édifices. Une sangle    Précision :
en métal réglable de 5 à 15 cm, permet à la zone de surface de la plaque en cuivre du             Capteur de température de thermistance : ±0.2°C @ 25°C ;
capteur d’avoir un bon contact avec la surface de la conduite. Dans le but de travailler avec     Capteur de température RTD : DIN Classe A ±0.15°C @ 0°C .
les régulateurs de bâtiments les plus courants, la sortie du capteur peut être choisie à partir   Limites de Température : Opérationnelle : -35.5 à +115.5°C.
de six différentes courbes de RTD et Thermistance. Les caractéristiques additionnelles incluent   Courbes de Capteur : Voir Résistance vs table de température p31.
un couvercle dévissable en un quart de tour ancré au boîtier pour prévenir tout risque de perte   Matériau du Boîtier : Répond aux exigences UL 94 V-0 plastique polycarbonate,
de l’appareil, ainsi que de multiples trous de fixation de diverses dimensions pour réduire le    NEMA 3R.
temps d’installation.                                                                             Poids : 198 g.
 Modèle           Type de Capteur                                                 Réf.
 TE-SNW-A         10KΩ Type III Thermistance                                    DWY50002
 TE-SNW-B         10KΩ Type II Thermistance                                     DWY50004
 TE-SNW-C         3KΩ Thermistance                                              3G-CBM-02315
 TE-SNW-D         Pt100Ω RTD                                                    DWY50008
 TE-SNW-E         Pt1000Ω RTD                                                   DWY50010
 TE-SNW-F         20KΩ Thermistance                                             DWY50012

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Dwyer Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

Where can I buy the Dwyer TE-SNW-C surface temperature sensor in the Philippines?

3G Electric Philippines supplies the Dwyer TE-SNW-C for industrial process control. We handle delivery to Manila and Quezon City, plus Bureau of Customs documentation and PHP invoicing. Lead time on request — contact our team for availability and quotation.

What is the measurement accuracy and operating range of the TE-SNW-C?

The Dwyer TE-SNW-C offers DIN Class A accuracy of ±0.15°C at 0°C (RTD) or ±0.2°C at 25°C (thermistance). Operating temperature range is -35.5 to +115.5°C, suitable for HVAC and process monitoring on 5 to 15 cm diameter pipes.

Is the TE-SNW-C housing rated for outdoor or wet environments?

Yes. The TE-SNW-C features a UL 94 V-0 polycarbonate housing rated NEMA 3R, providing protection for outdoor and wet industrial settings, including food processing and packaging plants.
