Dwyer PAFS-1009 average flow probe

The Dwyer PAFS-1009 is an average flow probe for HVAC and fluid systems, featuring 10 detection points across 6 mm ID tubing for enhanced measurement accuracy. Constructed from ABS/polycarbonate (UL94-5V), it…

SKU 3G-CBM-02231

Also listed as: DWY 30016 · DWY-30016

Brand

Dwyer

Item

PAFS-1009 average flow probe

Local availability & support — the Philippines

Delivery: 5–8 business days door-to-door; Bureau of Customs clearance typically 2–4 business days.
Payment: Invoicing in PHP or USD. Bank transfer and corporate PO accepted.
Ships to: Manila, Quezon City, Cebu, Davao, Batangas

Technical Specifications

Dwyer

model

PAFS-1009

material

ABS/polycarbonate (UL94-5V)

tubing id mm

6

tubing od mm

10

detection points

10

temperature storage

-40 to +60°C

temperature operational

4 to 49°C

Datasheet Content

Sonde de débit moyen

Idéal pour la mesure de débit de ventilation

La Série PAFS-1000 Sonde de Debit Moyen est indiquée pour détecter une pression
différentielle dans la section d’entiée d’unités terminales a volume d’cit variable et d’unités
terminales de ventilation. Les appareils peuvent également étre utilisés pour détecter la
pression différentielle en d‘autres endroits des systémes de conduite principaux et secondaires.
Le port “H” détecte la pression totale tandis que le port “L” détecte la pression statique. La
différence entre ces signaux correspond au différentiel, ou pression dynamique.

Pour les modéles de PAFS-1002 @ PAFS-1005, jusqu’d quatte points de détection et des
longueurs de 8.02 4 25.26 cm sont disponibles pour adapter le diamtre de Ia boite de 10.16
€ 40.64 cm. Pour les modéles de PAFS:1006 a PAFS -1011, jusqu’t dix points de détection et
des longueurs de 31.75 & 60.72 cm sont disponibles pour adapter les dimensions de conduite
Gi une taille adéquate,

SPECIFICATIONS
Service : Air et gaz compatible. Matériaux : ABS/polycarbonate (UL94-5V).
Limites de Température :

Opérationnelle : de 4 4 49°C ;

Stockage : de -40 4 +60°C.

Raccord : 6 mm ID, 10 mm OD de tubage.

Position de Montage : Bride intégrale avec joint. Poids : 28 g.

MOUNTING HOLES

2X03/16 [04.76]

PUSH-ON CONNECTIONS:
Bp FOR 3/8 POLY TUBING [9.53 OD]

3/4 mae

FOAM GASKET
1/8 THK [6.35 THK]

3178]
APPLICATIONS
Contidle de zone dans les systémes HVAC.
Modeéle Longueur (Dimension A) Ref.
PAFS-1002 | 8.02 cm WwY30002
PAFS-1003 | 13.73 cm WY30004
PAFS-1004 | 19.55 cm WY30006
PAFS-1005 | 25.26 cm WwY30008
PAFS-1006 | 31.75 cm WY30010
PAFS-1007 | 37.47 cm WY30012
PAFS-1008 | 43.50 cm WwY30014
PAFS-1009 | 49.29 cm WY30016
PAFS-1010 | 55.0] cm WY30018
PAFS-1011 | 60.72 cm wy30020

Dwyer

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Dwyer Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

Where can I buy the Dwyer PAFS-1009 flow probe in the Philippines?

Order directly from 3G Electric Philippines. We source the Dwyer PAFS-1009 and deliver to Manila and Quezon City. Lead time on request. 3G Electric handles Bureau of Customs documentation and logistics to your facility.

What is the lead time for the Dwyer PAFS-1009?

Lead time on request. 3G Electric sources the PAFS-1009 from international suppliers and manages all import documentation. We provide estimated delivery dates after quotation. Inquire at 3G Electric for current availability.

What are the operating conditions for the PAFS-1009 flow probe?

The Dwyer PAFS-1009 operates from 4°C to 49°C and features 10 detection points across 6 mm ID tubing for accurate distributed flow sensing in HVAC and fluid systems. Housing is ABS/polycarbonate, UL94-5V rated for safety compliance.
