APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, M5-0.80 Thread Size, Plain - Screw-Locking Tanged Helical Inserts
APPROVED VENDORScrew-Locking Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, M5-0.80 Thread Size, Plain

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert with M5-0.80 coarse thread size, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 psi, is compatible with…

SKU 3G-OTH-529063

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Screw-Locking, M5-0.80 Thread Size, Plain
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3520-5.00X1.5DSL
Type
Screw-Locking, M5-0.80 Thread Size, Plain, 10 PK
Tensile Strength
200,000 psi
Finish Type
Plain
Thread Type
Coarse
STI Tap Size
M5-0.80
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert with M5-0.80 coarse thread size, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 psi, is compatible with metal, and comes in a 10-pack. This metric, right-hand thread insert is designed for use with an STI tap size of M5-0.80.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

An APPROVED VENDOR helical insert is used to repair or strengthen internal threads in metal components. The screw-locking, tanged tang style provides vibration resistance, making it ideal for industrial machinery, automotive, and aerospace applications where thread integrity is critical.

What are the specifications of the APPROVED VENDOR M5-0.80 helical insert?

This helical insert has an M5-0.80 coarse thread size, 18-8 material grade, and a tensile strength of 200,000 psi. It is a right-hand, screw-locking tanged tang style with plain finish, compatible with metal, and requires an STI tap size of M5-0.80. Sold in a 10-pack.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this M5-0.80 screw-locking insert.

How to install a tanged helical insert?

To install a tanged helical insert, drill the hole to the specified size, tap it using the correct STI tap (M5-0.80 for this insert), then use a tang installation tool to wind the insert into the tapped hole. After installation, break off the tang with a punch. Always follow the manufacturer's instructions.
