APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, M5-0.80 Thread Size, Plain - Screw-Locking Tanged Helical Inserts
APPROVED VENDORScrew-Locking Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, M5-0.80 Thread Size, Plain

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert with M5-0.80 coarse thread size, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 psi, is right-hand…

SKU 3G-OTH-528814

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Screw-Locking, M5-0.80 Thread Size, Plain
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3520-5.00X1.0DSL
Type
Screw-Locking, M5-0.80 Thread Size, Plain, 10 PK
Tensile Strength
200,000 psi
Finish Type
Plain
Thread Type
Coarse
STI Tap Size
M5-0.80
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert with M5-0.80 coarse thread size, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 psi, is right-hand threaded, and compatible with metal. Supplied in a 10-pack, this metric insert is designed for use with an STI tap size of M5-0.80.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

An APPROVED VENDOR helical insert is used to repair or reinforce internal threads in metal components. The screw-locking, tanged tang style provides vibration resistance, making it suitable for industrial machinery, automotive, and aerospace applications where thread integrity is critical.

What are the specifications of the APPROVED VENDOR M5-0.80 helical insert?

This helical insert has an M5-0.80 coarse thread, 18-8 material grade, and a tensile strength of 200,000 psi. It is right-hand threaded, plain finish, and compatible with metal. The STI tap size is M5-0.80, and it comes in a 10-pack from APPROVED VENDOR.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver these screw-locking inserts to your facility. Contact us for availability and lead time on your order.

How to install a tanged tang style helical insert?

To install a tanged tang style helical insert, drill the hole to the specified STI tap size, tap threads using the correct STI tap, then insert the coil using a tang drive tool. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for best results.
