APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, 7/16"-20 Thread Size - Screw-Locking Tanged Helical Inserts
APPROVED VENDORScrew-Locking Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, 7/16"-20 Thread Size

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert in a 5-pack, featuring a 7/16"-20 fine thread size and plain finish. It is made from 18-8 material with a tensile strength of 200,000…

SKU 3G-OTH-529083

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Screw-Locking, 7/16"-20 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3534-7/16X1.5DSL
Type
Screw-Locking, Plain, 5 PK
Tensile Strength
200,000 psi
Finish Type
Plain
Thread Size
7/16"-20
Thread Type
Fine
STI Tap Size
7/16"-20
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert in a 5-pack, featuring a 7/16"-20 fine thread size and plain finish. It is made from 18-8 material with a tensile strength of 200,000 psi, designed for right-hand threading in metal applications. This inch-system insert uses an STI tap size of 7/16"-20 and is compatible with metal substrates.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

An APPROVED VENDOR helical insert repairs or strengthens threads in metal. This screw-locking, tanged tang style insert with 7/16"-20 fine threads provides a high-strength 200,000 psi tensile thread for applications like automotive, aerospace, and industrial equipment where vibration resistance is needed.

What are the specifications of the APPROVED VENDOR 3534-7/16X1.5DSL helical insert?

This 5-pack of screw-locking helical inserts has a 7/16"-20 fine thread size, plain finish, and 18-8 material grade. It features a tensile strength of 200,000 psi, right-hand thread direction, and requires an STI tap size of 7/16"-20. It is designed for inch-system metal applications.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us to order the 3534-7/16X1.5DSL 5-pack or other thread sizes for your maintenance or production needs.

How to install a tanged tang style helical insert?

To install an APPROVED VENDOR tanged tang helical insert, drill the hole to the specified size, tap it using the correct STI tap (7/16"-20 for this insert), then use a tang-style installation tool to wind the insert into the tapped hole. After installation, break off the tang with a punch for a flush finish.
