APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, #10-32 Thread Size, Plain - Screw-Locking Tanged Helical Inserts
APPROVED VENDORScrew-Locking Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, #10-32 Thread Size, Plain

APPROVED VENDOR Helical Insert: Tanged Tang Style, a screw-locking tanged helical insert with #10-32 fine thread size, plain finish, and 18-8 material grade. Supplied in a 10-pack, this inch-system insert has a…

SKU 3G-OTH-529072

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Screw-Locking, #10-32 Thread Size, Plain
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3534-10GX2.0DSL
Type
Screw-Locking, #10-32 Thread Size, Plain, 10 PK
Tensile Strength
200,000 psi
Finish Type
Plain
Thread Type
Fine
STI Tap Size
#10-32
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

APPROVED VENDOR Helical Insert: Tanged Tang Style, a screw-locking tanged helical insert with #10-32 fine thread size, plain finish, and 18-8 material grade. Supplied in a 10-pack, this inch-system insert has a tensile strength of 200,000 psi, right-hand thread direction, and is compatible with metal substrates.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

An APPROVED VENDOR helical insert repairs or strengthens threads in metal substrates. The screw-locking tanged style resists vibration loosening, making it ideal for automotive, aerospace, and industrial machinery applications where joint integrity is critical.

What are the specifications of the APPROVED VENDOR 3534-10GX2.0DSL helical insert?

This helical insert has a #10-32 fine thread, 18-8 material grade, 200,000 psi tensile strength, right-hand thread direction, and plain finish. It is supplied in a 10-pack and requires an STI tap size of #10-32 for installation.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver these screw-locking inserts to your facility, regardless of location.

How to install a tanged helical insert?

Install a tanged helical insert by drilling to the specified STI tap size, tapping the hole with the correct STI tap, then using a tang insertion tool to wind the insert into the thread. After installation, break off the tang with a punch for a permanent, vibration-resistant thread.
