AMERICAN LOUVER Diffuser: Ceiling, 23 3/4 in H, 23 3/4 in W, Lay-In, 8 in Duct, Plastic - Square Cone Diffusers
AMERICAN LOUVERSquare Cone Diffusers

AMERICAN LOUVER Diffuser: Ceiling, 23 3/4 in H, 23 3/4 in W, Lay-In, 8 in Duct, Plastic

The AMERICAN LOUVER Square Cone Diffuser (SKU 270H87, MPN STR-C-8W-R6) is a ceiling-mounted, lay-in diffuser with a white plastic construction. It measures 23 3/4 inches in height and width, features an 8-inch duct…

SKU 3G-OTH-76963

Brand
AMERICAN LOUVER
Item
Diffuser: Ceiling, 23 3/4 in H, 23 3/4 in W, Lay-In, 8 in Duct, Plastic
Category
Square Cone Diffusers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

AMERICAN LOUVER
H
23 3/4 in
Duct
8 in
Type
23 3/4 in W, Lay-In, Plastic, Square Cone, White
Brand
AMERICAN LOUVER
Color
White
Insulated
Yes
Adjustable Blades
No
Mounting Location
Ceiling
Manufacturer Part Number
STR-C-8W-R6
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

AMERICAN LOUVER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The AMERICAN LOUVER Square Cone Diffuser (SKU 270H87, MPN STR-C-8W-R6) is a ceiling-mounted, lay-in diffuser with a white plastic construction. It measures 23 3/4 inches in height and width, features an 8-inch duct connection, and is insulated with non-adjustable blades.
