Tritan 3G-OTH-104657 — Technical Specifications
The TRITAN Pillow Block Bearing (30 mm Bore) is a general purpose pillow block ball bearing with a cast iron housing and set screw locking. It features a 30 mm bore, 42.8 mm shaft height, 160 mm overall length, and M12 mounting bolt size, conforming to ISO standards in metric measurement (MPN UCP206-30MM).
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Cast Iron, Set Screws |
| Brand | TRITAN |
| Shaft Ht | 42.8 mm |
| Standards | ISO |
| Overall Lg | 160 mm |
| Mounting Bolt Size | M12 |
| System Of Measurement | Metric |
| Manufacturer Part Number | UCP206-30MM |
