Timken 3G-OTH-100099 — Technical Specifications
The TIMKEN Radial Ball Bearing: 6306 is a metric high-capacity retaining ring ball bearing with a 30 mm bore, 72 mm OD, and 19 mm outer ring width. It features a single shield and is identified by bearing industry number 6306 and manufacturer part number 306WDG.
Technical Specifications
| Parameter | Value |
|---|---|
| OD | 72 mm |
| Bore | 30 mm |
| Type | Sngl Shield, 1 |
| Outer Ring Wd | 19 mm |
| System Of Measurement | Metric |
| Bearing Industry Number | 6306 |
| Manufacturer Part Number | 306WDG |
