Square D 3G-OTH-22393 — Technical Specifications

Name: Square D 3G-OTH-22393 SQUARE D Miniature Circuit Breaker: 80 A, 277/480V AC, Single Phase, 18kA at 277/480V AC, 2 Poles (MPN EDB24080). Key specifications — Phase: Single; Amps: 80 A; AC Voltage Rating: 277/480V AC; Max. AIR Rating: 18kA at 277/480V AC; For Use With: Square D NF Panelboards; Brand: SQUARE D.
Brand: Square D

The SQUARE D EDB & EGB Series Miniature Circuit Breaker (SKU 3TW32, MPN EDB24080) is a 2-pole, single-phase, bolt-on circuit breaker rated for 80 A at 277/480V AC with a maximum AIR rating of 18kA at 277/480V AC. Designed for use with Square D NF Panelboards, this SQUARE D breaker provides overcurrent protection in industrial electrical distribution systems.

View Product & Quote

Technical Specifications

Parameter	Value
AC	277/480V
Amps	80 A
Type	Single Phase, 18kA at 277/480V AC
Brand	SQUARE D
Phase	Single
Poles	2
For Use With	Square D NF Panelboards
Max. AIR Rating	18kA at 277/480V AC
AC Voltage Rating	277/480V AC
Manufacturer Part Number	EDB24080
