Square D 3G-OTH-22342 — Technical Specifications

Name: Square D 3G-OTH-22342 SQUARE D Miniature Circuit Breaker: 60 A, 277V AC, Single Phase, 18kA at 120/240V AC, 1 Poles, Std (MPN EDB14060). Key specifications — Phase: Single; Amps: 60 A; AC Voltage Rating: 277V AC; Max. AIR Rating: 18kA at 120/240V AC; For Use With: Square D NF Panelboards; Brand: SQUARE D.
Brand: Square D

The SQUARE D EDB14060 is a 60 A, single-phase miniature circuit breaker from the EDB & EGB Series, rated for 277V AC with a maximum AIR rating of 18kA at 120/240V AC. This bolt-on breaker is designed for use with Square D NF Panelboards.

View Product & Quote

Technical Specifications

Parameter	Value
AC	277V
Amps	60 A
Type	Single Phase, 18kA at 120/240V AC, Std
Brand	SQUARE D
Phase	Single
Poles	1
For Use With	Square D NF Panelboards
Max. AIR Rating	18kA at 120/240V AC
AC Voltage Rating	277V AC
Manufacturer Part Number	EDB14060
