Square D 3G-OTH-41334 — Technical Specifications
The SQUARE D Magnetic Motor Starter is a non-reversing starter with thermal overloads, part number 8536SAO11V02S. It is a single-phase, 2-pole, NEMA Size 00 unit rated for 9 A with a 120V AC coil. This starter features screw clamp terminals and requires one melting alloy thermal unit (not included). It includes no operator, no pilot light, no operator controls, and no auxiliary contacts.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | NEMA Size 00, 9 A |
| Brand | SQUARE D |
| Phase | Single |
| Poles | 2 |
| AC Coil | 120V |
| Operator | None |
| Coil Voltage | 120V AC |
| Operator Controls | None |
| Includes Pilot Light | No |
| Thermal Units Required | 1 Melting Alloy Unit (Not Included) |
| Manufacturer Part Number | 8536SAO11V02S |
| Terminal Connection Type | Screw Clamp Terminals |
| Auxiliary Contacts Included | No Auxiliary Contacts Included |
