Square D 3G-OTH-40470 — Technical Specifications
The SQUARE D Magnetic Motor Starter is a non-reversing starter with thermal overloads, part number 8536SBO1V02. It is a NEMA Size 0, 2-pole, single-phase unit rated at 18 A with a 110/120V AC coil voltage. This model features screw clamp terminals, no operator controls, no auxiliary contacts, and requires one melting alloy thermal unit (not included).
Technical Specifications
| Parameter | Value |
|---|---|
| Type | NEMA Size 0, 18 A |
| Brand | SQUARE D |
| Phase | Single |
| Poles | 2 |
| AC Coil | 120V |
| Operator | None |
| Coil Voltage | 110/120V AC |
| Operator Controls | None |
| Includes Pilot Light | No |
| Thermal Units Required | 1 Melting Alloy Unit (Not Included) |
| Manufacturer Part Number | 8536SBO1V02 |
| Terminal Connection Type | Screw Clamp Terminals |
| Auxiliary Contacts Included | No Auxiliary Contacts Included |
