Smc 3G-OTH-189589 — Technical Specifications

Name: Smc 3G-OTH-189589 SMC Compact Cylinder: 32 mm Bore Dia, 20 mm Stroke Lg, Through Hole Mounting, Aluminum, 1/8 in BSPT (MPN CQ2B32-20DCZ). Key specifications — attr946022: Through Hole; attr946024: Single Rod; attr946038: CQ2; attr1123057: Rotating Rod; attr945997: SMC.
Brand: Smc

The SMC CQ2B32-20DCZ is a compact cylinder from the CQ2 series, featuring a 32 mm bore diameter and 20 mm stroke length. It is a through-hole mount, single-rod, rotating-rod cylinder constructed of aluminum with a 1/8 in BSPT port. This product is designed for applications requiring a compact, rotating-rod pneumatic actuator.

View Product & Quote

Technical Specifications

Parameter	Value
BSPT	1/8 in
Type	Through Hole Mounting, Aluminum
Stroke Lg	20 mm
Manufacturer Part Number	CQ2B32-20DCZ
