Smc 3G-OTH-189585 — Technical Specifications

Name: Smc 3G-OTH-189585 SMC Compact Cylinder: 20 mm Bore Dia, 10 mm Stroke Lg, Tapped Hole/Through Hole Mounting, Aluminum (MPN CDQSB20-10DCM). Key specifications — attr946022: Through Hole; attr946024: Single Rod; attr946038: CQS; attr1123057: Rotating Rod; attr945997: SMC.
Brand: Smc

The SMC CDQSB20-10DCM is a CQS series compact cylinder with a 20 mm bore diameter and 10 mm stroke length, featuring a single rod and rotating rod design. It offers through hole mounting and is constructed with aluminum. This through hole mount compact cylinder is designed for applications requiring a compact, rotating rod actuator.

View Product & Quote

Technical Specifications

Parameter	Value
Type	Tapped Hole/Through Hole Mounting, Aluminum
Stroke Lg	10 mm
Manufacturer Part Number	CDQSB20-10DCM
