Smc 3G-OTH-189564 — Technical Specifications

Name: Smc 3G-OTH-189564 SMC Compact Cylinder: 80 mm Bore Dia, 40 mm Stroke Lg, Tapped Hole/Through Hole Mounting, Aluminum (MPN CD55B80-40). Key specifications — attr946022: Through Hole; attr946024: Single Rod; attr946038: C55; attr1123057: Rotating Rod; attr945997: SMC.
Brand: Smc

The SMC Compact Cylinder (MPN CD55B80-40) is a through-hole mount compact cylinder from the C55 series, featuring an 80 mm bore diameter and 40 mm stroke length. It is a single-rod, rotating-rod design constructed from aluminum. This product is designed for applications requiring a compact, through-hole mounting configuration.

View Product & Quote

Technical Specifications

Parameter	Value
Type	Tapped Hole/Through Hole Mounting, Aluminum
Stroke Lg	40 mm
Manufacturer Part Number	CD55B80-40
