Siemens 3G-OTH-42766 — Technical Specifications

Name: Siemens 3G-OTH-42766 SIEMENS Definite Purpose Contactor: 2 Poles, 120V AC, 40 A, Non-Reversing, Std Contactor Frame Size (MPN 42CF15AF). Key specifications — Brand: SIEMENS; Coil Voltage: 110/110-120V AC; Mounting Style: Surface; Terminal Connection Type: Quick Disconnect and Screw/Box Lug; Maximum Voltage Rating: 600V AC; Series: 42 Series; Phase: Single; Main Pole Contact Form: 2NO.
Brand: Siemens

The SIEMENS Definite Purpose Contactor is a non-reversing, 2-pole contactor from the 42 Series, designed for single-phase applications. It features a 110/110-120V AC coil voltage, a 2NO main pole contact form, and a maximum voltage rating of 600V AC. This surface-mount contactor offers quick disconnect and screw/box lug terminal connections.

View Product & Quote

Technical Specifications

Parameter	Value
AC	120V
Type	40 A, Non-Reversing, Std Contactor Frame Size
Brand	SIEMENS
Phase	Single
Series	42 Series
Coil Voltage	110/110-120V AC
Mounting Style	Surface
Main Pole Contact Form	2NO
Maximum Voltage Rating	600V AC
Manufacturer Part Number	42CF15AF
Terminal Connection Type	Quick Disconnect and Screw/Box Lug
