Siemens 3G-OTH-22416 — Technical Specifications

Name: Siemens 3G-OTH-22416 SIEMENS Molded Case Circuit Breaker: 80 A Amps, 42kA at 480V AC, Fixed, Load Side Lug, Any, HED4 (MPN HED42B080). Key specifications — Phase Connection: Any; Instantaneous Trip: Fixed; Terminal Connection: Load Side Lug; Series: HED4; Max. AIR Rating: 42kA at 480V AC.
Brand: Siemens

The Siemens HED4 ED-Frame Molded Case Circuit Breaker (MPN HED42B080) is an 80 A rated device with a maximum AIR rating of 42kA at 480V AC. It features a fixed instantaneous trip, load side lug terminal connection, and supports any phase connection.

View Product & Quote

Technical Specifications

Parameter	Value
Type	42kA at 480V AC, Fixed, Load Side Lug, Any, HED4
Series	HED4
Max. AIR Rating	42kA at 480V AC
Phase Connection	Any
Instantaneous Trip	Fixed
Terminal Connection	Load Side Lug
Manufacturer Part Number	HED42B080
