Schneider 3G-OTH-42265 — Technical Specifications
The SCHNEIDER Overload Relay: Thermal Protection (MPN LR2D3559) is an IEC thermal overload relay with integrated bimetallic elements, rated for 48 A – 65 A and a maximum voltage of 1000V AC. It features 1NO/1NC auxiliary contacts, screw clamp terminals, and phase loss sensitivity. This relay is compatible with TeSys Deca contactors (80 to 95 Amp models) and requires no external thermal units.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | 1NO/1NC, Phase Loss Sensitivity, 48 A – 65 A |
| Brand | SCHNEIDER |
| Poles | 3 |
| Compatible Contactors | TeSys Deca (80 to 95 Amp Models) |
| Auxiliary Contact Form | 1NO/1NC |
| Maximum Voltage Rating | 1000V AC |
| Phase Loss Sensitivity | Yes |
| Thermal Units Required | None (Relay Includes Integrated Bimetallic Elements) |
| Manufacturer Part Number | LR2D3559 |
| Terminal Connection Type | Screw Clamp Terminals |
| Compatible Contactor Series | TeSys Deca |
