Schneider 3G-OTH-39571 — Technical Specifications

Name: Schneider 3G-OTH-39571 SCHNEIDER Solid State Relay: Surface Mounted, 50 A Max Output Current, SCR, AC Output (MPN SSP3A250BD). Key specifications — Brand: SCHNEIDER; Current Type: DC; Electrical Connection: Screw Clamp; Finger Safe: Yes; Input Current: 24 to 35 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel; Output Voltage: 48 to 530V AC.
Brand: Schneider

The SCHNEIDER Solid State Relay is a surface-mounted, panel-mounted relay with a Form A switch configuration and AC output. It features a DC input current of 24 to 35 mA, an output voltage of 48 to 530V AC, and a screw clamp electrical connection. This finger-safe relay is designed for applications where a heat sink is not recommended for maximum output current.

View Product & Quote

Technical Specifications

Parameter	Value
Type	SCR, AC Output
Brand	SCHNEIDER
Finger Safe	Yes
Current Type	DC
Input Current	24 to 35 mA
Mounting Style	Panel
Output Voltage	48 to 530V AC
Max Output Current	50 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	SSP3A250BD
Maximum Output Current Without Heat Sink	Not Recommended
